Запчасти Case IH 4494 (2-018) - INTAKE MANIFOLD, 504BDT DIESEL ENGINE (02) - ENGINE

1

A154446

MANIFOLD

ASSEMBLY - intake, Includes: Ref. 2 - 4

1шт.

2

A20916

MANIFOLD GASKET

GASKET - plug

2шт.

3

L10283

PLUG

- heater hole

2шт.

4

221-1849

PLUG

- slotted headless, 1/8 inch PT

2шт.

6

A58662

MANIFOLD GASKET

- intake, Serial Range: manifold-head

6шт.

7

A59077

STUD

- intake manifold, 3/8 NC x 1-13/16 inch

12шт.

8

195-525

WASHER,3/8", SAE

- 13/32 x 13/16 x 1/16 inch (10 x 21 x 2 mm)

12шт.

9

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

12шт.

10

25-166

NUT,3/8"-16, G5, Hvy

- hex, 3/8 inch NC

12шт.

13

A150450

ELBOW

- turbocharger intake

1шт.

14

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

- hex, 3/8 NC x 1-1/2 inch

4шт.

17

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, 3/8"-16, G5

4шт.

18

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

19

A58910

GASKET

- elbow flange

1шт.
