Артикул
Название
Примечание
Количество
1
G33769
CYLINDER
ASSEMBLY - hydraulic, Includes: Ref. 2 - 38
1шт.
2
G33772
ROD
- piston
1шт.
3
G34980
COLLAR
- stop
1шт.
4
G34977
BOLT
- hook
1шт.
5
G34979
PLUG
- locking
1шт.
6
187-1515
SELF-TAP SCREW,1/4" - 20 x 3/4"
SCREW - self-tapping, 1/4 NC x 1/2 inch
1шт.
7
G32075
PLATE
- stop
1шт.
g
G104933
CYLINDER
GLAND ASSEMBLY - packing, Includes: Ref. 8 - 15
1шт.
8
NSS
NOT SOLD SEPARAT
GLAND - cylinder (Order G104933)
1шт.
10
NSS
NOT SOLD SEPARAT
RING - center bearing (Order G104933)
1шт.
11
D95142
WIPER SEAL,1.5" ID x 2" OD x 0.31" Thk
WIPER - piston rod
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
12
G102424
BUSHING,38.1mm ID x 41.17mm OD x 25.15mm L
BEARING - Center
1шт.
13
G107921
SEAL,38.07mm ID x 50.93mm OD x 10.69mm Thk
- piston rod
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
14
G32176
BACK-UP RING,101.22mm ID x 107.32mm OD x 1.4mm Thk
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
15
A27507
O-RING,0.139" Thk x 3.984" ID, -242, Cl 5, 75 Duro
- gland
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
16
G15457
O-RING,0.139" Thk x 3.484" ID, -238, Cl 5, 75 Duro
- piston
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
17
G31928
RING
- seal, teflon
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
18
G100448
RING,101.6mm OD, Ext
- wear, teflon
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
19
G33774
PISTON
- cylinder
1шт.
20
28-1232
BOLT,Hex, 3/4" - 16 x 2", Gr 8
1шт.
21
187-1524
SELF-TAP SCREW,Hex Hd, #8 x 3/8"
SCREW - self locking, gland (Replaces G102569 plug)
1шт.
22
G109093
SEAL,37.72mm ID x 50.98mm OD x 3.05mm Thk
- gland
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
23
G31942
HYD TUBE,15.15" L
TUBE - cylinder
1шт.
24
G32428
ROD
- push
1шт.
25
G32429
RING
- retaining
2шт.
26
G31934
SPRING
- rod return, 2-5/16 inch (59 mm) free length
1шт.
27
A8613
O-RING,0.426" ID x 0.566" OD
- sleeve (Order N8538)
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
28
G32427
SLEEVE
- protector
1шт.
29
49485
SNAP RING,#X18, .122" Dia, E-Type
Ring, Retaining, #X18, .122" Dia, E-Type
1шт.
30
G31980
SPRING
- plunger return, 1 inch (25 mm) free length
1шт.
31
G31929
WASHER
- 7/32 x 5/8 x 1/16 inch (6 x 16 x 2 mm)
1шт.
32
G31932
WIPER SEAL
SEAL - wiper, 3/16 x 1/2 x 1/8 inch (5 x 13 x 3 mm)
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
33
G31933
GLAND
ASSEMBLY - valve, Includes: Ref. 34 and 35
1шт.
34
G31935
O-RING,0.174" ID x 0.377" OD
- 11/64 inch (4 mm) ID
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
35
G31948
WASHER
- 13/64 ID x 1/16 inch width (5 ID x 2 mm width)
1шт.
37
G31943
PLUNGER
- valve
1шт.
38
G32070
O-RING,0.103" Thk x 0.424" ID, -11, Cl 6, 90 Duro
- plunger
1шт.
G109478
GASKET KIT
KIT - cylinder repair, Includes: Refs. 11, 13, 14, 15, 16, 17, 18, 22, 27, 32, 34, and 36
1шт.
36
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
- 41/64 ID x 3/32 inch width (16 ID x 2 mm width)
1шт.
Part of Cylinder Repair Kit, P/N G109748
1шт.
Выбрано товаров: 51
