Запчасти Case IH 4494 (6-216) - FRONT AXLE DIFFERENTIAL AND CARRIER, NO SPIN DIFFERENTIAL, PRIOR TO AXLE SERIAL NO. 13015953 (06) - POWER TRAIN

Схема запчастей Case IH 4494 - (6-216) - FRONT AXLE DIFFERENTIAL AND CARRIER, NO SPIN DIFFERENTIAL, PRIOR TO AXLE SERIAL NO. 13015953 (06) - POWER TRAIN
49
57
51
58
48
59
45
52
1
49
50
46
53
54
46
47

Артикул

Название

Примечание

Количество

A157447

CARRIER

ASSEMBLY - no spin differential, front axle (Continued from Figure 6-214), Includes: Ref. 45 - 59 and 3 - 41 on Fig. 6-214

1шт.

45

L33062

ROLLER BEARING

BEARING - roller, drive pinion

1шт.

46

A44210

ROLLER BEARING,1.75" ID x 1.25"

CONE - bearing, pinion shaft, 1-3/4 inch (44 mm) ID

2шт.

A44230

CAGE ASSY.,4.250" OD

CAGE ASSEMBLY - pinion bearing

1шт.

47

A45631

PIN

- guide

1шт.

48

NSS

NOT SOLD SEPARAT

CAGE - bearing (Order A44230)

1шт.

49

F61284

BEARING CUP

CUP - bearing, pinin shaft, 3-3/4 inch (95 mm)

2шт.

50

A44232

SHIM,.003" Thk

Bearing cage (0.076 mm) .003" Thk

1шт.

50

A44233

SHIM,.005" Thk

Bearing cage (0.127 mm) .005" Thk

1шт.

50

A44234

SHIM,.010" Thk

Bearing cage (0.254 mm) .010" Thk

1шт.

50

A44235

SHIM,.020" Thk

Bearing cage (0.508 mm) .020" Thk

1шт.

50

A44236

SHIM,.030" Thk

Bearing cage (0.762 mm) .030" Thk

1шт.

51

A45587

BUSHING

SPACER - pinion bearing, 0.514 (13.056 mm)

1шт.

51

A45588

BUSHING

SPACER - pinion bearing, 0.522 inch (13.259 mm)

1шт.

51

A45589

BUSHING

SPACER - pinion bearing, 0.530 inch (13.462 mm)

1шт.

51

A45590

BUSHING

SPACER - pinion bearing, 0.538 inch (13.665 mm)

1шт.

51

A45591

BUSHING

SPACER - pinion bearing, 0.542 inch (13.767 mm)

1шт.

52

A44212

BOLT

- bearing cage

6шт.

53

193-33

LOCK WASHER,9/16"

WASHER - lock, 9/16 inch

6шт.

54

A45567

NUT

- yoke to pinon shaft

1шт.

57

A44209

WASHER

- yoke to pinion shaft

1шт.

58

A44700

YOKE

- drive shaft

1шт.

59

A47594

OIL SEAL

ASSEMBLY - oil, pinion shaft (Replaces A48857)

1шт.

Выбрано товаров: 23
