Запчасти Case IH 4494 (6-212) - FRONT AXLE DIFFERENTIAL AND CARRIER, STANDARD DIFFERENTIAL, AXLE SERIAL NO. 13015953 AND AFTER (06) - POWER TRAIN

A179684

CARRIER

ASSEMBLY - standard differential, front axle (Continued from Fig 6-210), Includes: Ref. 45 - 59 and 2 - 44 on Fig. 6-210

1шт.

45

L33062

ROLLER BEARING

BEARING - roller, drive pinion

1шт.

46

A52295

ROLLER BEARING,44.45 mm ID x 26.909 mm

CONE - bearing, pinion shaft

2шт.

A45671

CAGE ASSY.

CAGE ASSEMBLY - pinion bearing, Includes: Ref. 48 and 49

1шт.

48

NSS

NOT SOLD SEPARAT

CAGE - bearing (Order A45671)

1шт.

49

A9840

BEARING CUP

CUP - bearing, pinion shaft

2шт.

50

S68370

SHIM,.003" Thk

Bearing cage (0.076 mm) .003" Thk

1шт.

50

A68371

SHIM - bearing cage, 0.005 inch (0.127 mm)

1шт.

50

S68362

SHIM,.0100" Thk

Bearing cage (0.254 mm) .0100" Thk

1шт.

50

S68363

LOCK

SHIM - bearing cage, 0.020 inch (0.508 mm)

1шт.

50

A75901

SHIM - bearing cage, 0.030 inch (0.762 mm) (0.762 mm)

1шт.

51

A52317

SPACER

- pinion bearing 0.623 inch (15.824 mm)

1шт.

51

A52318

SPACER

- pinion bearing, 0.624 inch (15.850 mm)

1шт.

51

A52319

SPACER

- pinion bearing, 0.625 inch (15.875 mm)

1шт.

51

A52320

SPACER

- pinion bearing, 0.626 inch (15.900 mm)

1шт.

51

A52321

SPACER

- pinion bearing, 0.627 inch (15.926 mm)

1шт.

51

A52322

SPACER

- pinion bearing, 0.628 inch (15.951 mm)

1шт.

51

A52323

SPACER

- pinion bearing, 0.629 inch (15.977 mm)

1шт.

51

A52324

SPACER

- pinion bearing, 0.630 inch (16.002 mm)

1шт.

51

NLS

NO LONGER SERVICED

- pinion bearing, 0.631 inch (16.027 mm)

1шт.

51

A52326

SPACER

- pinion bearing, 0.632 inch (16.053 mm)

1шт.

51

A52327

SPACER

- pinion bearing, 0.633 inch (16.078 mm)

1шт.

51

A52328

SPACER

- pinion bearing, 0.634 inch (16.104 mm)

1шт.

51

A52330

SPACER

- pinion bearing, 0.635 inch (16.129 mm)

1шт.

51

A52332

SPACER

- pinion bearing, 0.636 inch (16.154 mm)

1шт.

51

A52334

SPACER

- pinion bearing, 0.637 inch (16.180 mm)

1шт.

51

A52335

SPACER

- pinion bearing, 0.63758 inch (16.181 mm)

1шт.

51

A52336

SPACER

- pinion bearing, 0.638 inch (16.205 mm)

1шт.

51

A52338

SPACER

- pinion bearing, 0.639 inch (16.231 mm)

1шт.

51

A52340

SPACER

- pinion bearing, 0.640 inch (16.260 mm)

1шт.

51

A52342

SPACER

- pinion bearing, 0.641 inch (16.281 mm)

1шт.

51

A52344

SPACER

- pinion bearing, 0.642 inch (16.307 mm)

1шт.

51

A52345

SPACER - pinion bearing, 0.6425 inch (16.308 mm)

1шт.

51

A52346

SPACER

- pinion bearing, 0.643 inch (16.332 mm)

1шт.

51

A52348

- pinion bearing, 0.644 inch (16.358 mm)

1шт.

51

A52349

SPACER

- pinion bearing, 0.645 inch (16.383 mm)

1шт.

51

A52350

SPACER

- pinion bearing, 0.646 inch (16.408 mm)

1шт.

51

A52351

SPACER

- pinion bearing, 0.647 inch (16.434 mm)

1шт.

51

A52352

SPACER

- pinion bearing, 0.648 inch (16.459 mm)

1шт.

51

A52353

SPACER

- pinion bearing, 0.649 inch (16.485 mm)

1шт.

51

A52354

SPACER

- pinion bearing, 0.650 inch (16.510 mm)

1шт.

51

A52355

SPACER

- pinion bearing, 0.651 inch (16.535 mm)

1шт.

51

A52356

SPACER

- pinion bearing, 0.652 inch (16.561 mm)

1шт.

51

A52357

SPACER

- pinion bearing, 0.653 inch (16.586 mm)

1шт.

51

A52358

SPACER

- pinion bearing, 0.654 inch (16.612 mm)

1шт.

52

13-924

BOLT,Hex, 9/16" - 12 x 1-1/2", Gr 5

- bearing cage

6шт.

54

A45567

NUT

- yoke to pinion shaft

1шт.

57

A44209

WASHER

- yoke to pinion shaft

1шт.

58

A47568

YOKE

- drive shaft

1шт.

REF: 58 ECN C971234 IS RELEASING A 6C YOKE ASSY TO REPLACE A47568 YOKE. CUSTOMER WILL ALSO NEED NEW METRIC HWD. PARTS AS FOLLOWS: 317788A1 6 C YOKE WITH MUD SLING 253863A1 PINION GEAR SET 253988A1 PINION SHAFT WASHER AND 258056A1 DIFF PIN BEARING.

1шт.

59

A48856

SEAL

ASSEMBLY - oil, pinion shaft

1шт.
