Запчасти Case IH 4490 (2-020) - INTAKE MANIFOLD, 504BDT DIESEL ENGINE (02) - ENGINE

1

A154446

MANIFOLD

ASSEMBLY - intake, Includes: Ref. 2 - 4

1шт.

2

A20916

MANIFOLD GASKET

GASKET - plug

2шт.

3

L10283

PLUG

- heater hole

2шт.

4

221-1021

DRAIN PLUG,Sq Soc, 1/4"-18 NPTF

PLUG - 1/8" PT slotted headless

2шт.

6

A58662

MANIFOLD GASKET

- intake, Serial Range: manifold-head

6шт.

7

A59077

STUD

- intake manifold, 3/8" NC x 1-13/16"

12шт.

8

195-25

WASHER,3/8"

- 13/32 x 13/16 x 1/16" (10.32 x 20.64 x 1.6 mm)

12шт.

9

92-6

LOCK WASHER,3/8"

12шт.

10

25-166

NUT,3/8"-16, G5, Hvy

- 3/8" NC hex

12шт.

13

A150450

ELBOW

- turbocharge intake

1шт.

14

113-209

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

4шт.

17

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, 3/8"-16, G5

4шт.

18

92-6

LOCK WASHER,3/8"

4шт.

19

A58910

GASKET

- elbow flange

1шт.
