(018) - INTAKE MANIFOLD, 674 CUBIC INCH DIESEL ENGINE

Запчасти Case IH 2870 (018) - INTAKE MANIFOLD, 674 CUBIC INCH DIESEL ENGINE (02) - ENGINE

Схема запчастей Case IH 2870 - (018) - INTAKE MANIFOLD, 674 CUBIC INCH DIESEL ENGINE (02) - ENGINE
15
10
4
3
2
9
5
12
11
14
16
21
20
5
16
1
23
22
15
13
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

A45781

MANIFOLD

- intake

1шт.

2

A45843

PLUG

- intake manifold

1шт.

3

513-707

BOLT

- 10 x 1.5 x 35 mm, hex head

20шт.

4

195-525

WASHER,3/8", SAE

- 13/32 x 13/16 x 1/16" (10.32 x 20.64 x 1.59 mm)

20шт.

5

A46360

GASKET

- intake manifold to head (Replaces A45782)

2шт.

9

A46362

GASKET

- elbow to manifold (Replaces A45783)

1шт.

10

A45784

FITTING

ELBOW -, Serial Range: intake-turbocharger

1шт.

11

A45785

PLUG

- elbow

1шт.

12

A45788

SEALING WASHER

- plug

1шт.

13

513-707

BOLT

- 10 x 1.5 x 35 mm, hex head

2шт.

14

195-525

WASHER,3/8", SAE

- 13/32 x 13/16 x 1/16" (10.32 x 20.64 x 1.59 mm)

2шт.

15

A46292

HOSE

- intake tube to turbocharger (Replaces A45786)

2шт.

16

214-264

HOSE CLAMP,#52, 2.81" - 3.75", Type F Worm

CLAMP - hose, 2-13/16 to 3-3/4" (71.44 to 95.25 mm)

4шт.

20

A45787

TUBE

- turbocharger

1шт.

21

A45764

PLUG

- tube

1шт.

22

A45766

GASKET

WASHER - plug

1шт.

23

A45790

TURBOCHARGER

- (See figure 26)

1шт.
