Запчасти Case IH 2470 (298) - CAB, PLENUM WITH AIR CONDITIONER, LOWER, 1ST USED CAB SERIAL NO. 7813600 (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 2470 - (298) - CAB, PLENUM WITH AIR CONDITIONER, LOWER, 1ST USED CAB SERIAL NO. 7813600 (09) - CHASSIS/ATTACHMENTS
37
27
6
22
16
28
4
2
38
13
25
31
30
14
34
8
33
15
3
21
5
9
32
7
11
33
1
10
23
35
24
20
26
34
36
12

Артикул

Название

Примечание

Количество

1

F63646

EVAPORATOR

- air conditioner operation

1шт.

2

F63726

VALVE

- expansion

1шт.

3

NSS

NOT SOLD SEPARAT

INSULATION - valve (Order A42902)

1шт.

A42902

SEALING STRIP

INSULATION - (2-1/2" wide 30 ft. roll)

1шт.

4

F63727

TUBE

- equalizer

1шт.

5

222-993

GASKET,3/8 Tube, Fl, Copper

1шт.

6

222-995

SEALING WASHER,15.88mm ID

- 45 degrees, #10 copper

1шт.

7

F63753

HOSE

- high side (75-1/2")

1шт.

8

F63668

TUBE,0.38" OD x 9.25" L

- high side hose to coupling

1шт.

9

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP - equalizer tube & valve (9/16" to 1-1/16")

2шт.

10

A61195

O-RING,0.364" ID x 0.5" OD

"O" RING - coupling (23/64 x 1/2 x 1/16")

1шт.

11

A42663

COUPLING,1/2" - 20 NPT

COUPLING - cab, Includes: Ref. 12

1шт.

12

A42665

O-RING,0.239" ID x 0.375" OD x 0.07"

"O" RING - coupling piston

1шт.

13

A61196

COUPLING, BREAK AWAY

COUPLING - tractor, Includes: Ref. 14

1шт.

14

A42667

GASKET

- coupling

1шт.

15

A61195

O-RING,0.364" ID x 0.5" OD

"O" RING - coupling (23/64 x 1/2 x 1/16")

1шт.

16

REF

INSTRUCTION

HOSE - to receiver drier (See figures 318-322)

1шт.

20

F63754

HOSE

- low side (78-5/16")

1шт.

21

F63526

TUBE

-, Serial Range: hose-coupling

1шт.

22

A61197

O-RING,1.78mm Thk x 27mm ID

"O" RING - coupling (1-3/64 x 1-13/16 x 1/16")

1шт.

23

A42664

COUPLING, BREAK AWAY

COUPLING - cab, Includes: Ref. 24

1шт.

24

A42666

O-RING,0.737" ID x 0.943" OD x 0.103"

"O" RING - coupling piston

1шт.

25

A61194

COUPLING, BREAK AWAY

COUPLING - tractor half, Includes: Ref. 26

1шт.

26

A42668

GASKET

- coupling

1шт.

27

A61197

O-RING,1.78mm Thk x 27mm ID

"O" RING - coupling to hose (1-3/64 x 1-13/16 x 1/16")

1шт.

28

REF

INSTRUCTION

HOSE - coupling to compressor (See figures 318-322)

1шт.

30

49852

PTO SHAFT

- tube, 3/8" I.D.

1шт.

31

T34922

BUSHING

SPACER - clamp, 13/32 x 9/16 x 31/32"

1шт.

32

113-120

BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5

1шт.

33

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

34

9635082

NUT,5/16" - 18, Gr 5

2шт.

35

49855

CLAMP

- tube, 5/8" I.D.

1шт.

36

T39053

SPACER - clamp, 15/32 x 3/4 x 27/64"

1шт.

37

113-104

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

1шт.

38

195-521

WASHER,5/16", SAE

- flat (5/16")

1шт.

Выбрано товаров: 35
