Запчасти Case IH 2470 (263A) - DECALS, USED PRIOR TO TRACTOR SERIAL NO. 8762001 (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 2470 - (263A) - DECALS, USED PRIOR TO TRACTOR SERIAL NO. 8762001 (09) - CHASSIS/ATTACHMENTS
9
12
11
23
16
8
4
24
6
3
10
15
17
13
14
1
18
2

Артикул

Название

Примечание

Количество

A43181

KIT

DECAL KIT - standard, Includes: Ref. 1 - 18

1шт.

1

321-2161

DECAL

- "504 Turbo-Charged", hood side

2шт.

2

321-2160

DECAL

- "2470", side front hood

2шт.

3

321-2647

DECAL

- "Console Top" (Replaces 321-2157 & 321-2452)

1шт.

4

321-2156

DECAL - "Instrument Panel", w/rear steering

1шт.

6

321-2155

DECAL - "Instrument Panel", w/o rear steering

1шт.

8

321-1335

DECAL

- "Seat Adjustment Indicator"

1шт.

9

321-2163

DECAL

- "Case", side front hood

2шт.

10

321-1841

DECAL

- "Ether Operation"

1шт.

11

321-122

DECAL

- "Caution", radiator cap removal

1шт.

12

321-2427

EMBLEM

DECAL - "Case", cab rear

1шт.

13

321-367

DECAL

- "Important", engine oil filter

2шт.

14

321-230

DECAL

- "Diesel Fuel", tank filler

2шт.

15

321-2137

DECAL

- "Engine Data"

1шт.

16

321-1062

DECAL

- "Negative Ground", battery case

2шт.

17

321-2470

DECAL

- trans. oil level

1шт.

18

321-608

DECAL

- "Be Careful" - P.T.O. shield

1шт.

23

321-2565

DECAL

- "Case - David Brown"

2шт.

24

321-2652

DECAL

- travel (MPH)

1шт.

Выбрано товаров: 19
