Запчасти Case IH 2470 (154) - REAR HYDRAULIC STEERING (05) - STEERING

1

A145273

VALVE

ASSEMBLY - control, rear steering (See figure 164)

1шт.

2

218-5108

ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

Assy, adjustable, Incl. Ref. 3 90º, 1 1/16"-12, 37º x 1 1/16"-12, O-Ring

1шт.

3

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

- 3/4 x 59/64 x 1/8" (19.05 x 23.42 x 3.17 MM)

1шт.

4

A77043

HOSE

- inlet, rear steering

1шт.

5

A138373

HOSE

- pressure, rear steering, used with PTO (Replaces A77034)

1шт.

6

A138372

HOSE

- pressure, rear steering, used without PTO (Replaces A77033)

1шт.

7

218-5064

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

CONNECTOR ASSEMBLY - straight, Incl. Ref. 8

3шт.

8

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

- 3/4 x 59/64 x 1/8" (19.05 x 23.42 x 3.17 MM)

1шт.

9

A77046

HOSE

- return, rear steering

1шт.

10

A138371

TUBE

- return, rear steering (See A139726)

1шт.

10

A139726

TUBE

- return, rear steering, use with spin on type filters

1шт.

11

218-5136

ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

ASSEMBLY - 45 degree adjustable, Incl. Ref 12

1шт.

13

A77049

HOSE

- rear steering cylinder, LH

1шт.

14

A138368

TUBE

- rear steering cylinder LH (Replaces A77051)

1шт.

15

A138196

HOSE

- rear steering tube to check valve

2шт.

16

218-5059

HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring

CONNECTOR ASSEMBLY - straight, Incl. Ref 17

2шт.

18

A138370

TUBE

- rear steering cylinder, RH (Replaces A77050)

1шт.

19

A77048

HOSE

- rear steering cylinder, RH

1шт.

20

218-5106

90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

ASSEMBLY - 90 degree adjustable, Includes: Ref. 21

1шт.

22

A77054

VALVE

ASSEMBLY - check, rear steering (See figure 166)

1шт.

23

49838

CLAMP

- tube (1/2" tube ID)

7шт.

24

515-23190

CLAMP,3/4", Insul, 3/8" Bolt

- tube (3/4" ID)

2шт.

25

187-1304

SELF-TAP SCREW,Cross Flat Hd, 3/8"-16 x 3/4"

SCREW - 3/8"-16 x 3/4"

4шт.

26

113-219

BOLT,Hex, 3/8" - 16 x 2", Gr 5

2шт.

27

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

28

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, 3/8"-16, G5

2шт.

29

A76093

BUSHING

SPACER - tube clamps, 13/32 x 3/4 x 1/2" (10.32 x 19.05 x 12.7 MM)

2шт.

12

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 1/2 x 21/32 x 3/32" (12.7 x 16.67 x 2.38 MM)

1шт.

17

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 1/2 x 21/32 x 3/32" (12.7 x 16.67 x 2.38 MM)

1шт.

21

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 1/2 x 21/32 x 3/32" (12.7 x 16.67 x 2.38 MM)

1шт.
