Запчасти Case IH 2470 (208) - RANGE SHIFT MECHANISM (06) - POWER TRAIN

1

A136325

LEVER

- shift, straight (Transmission serial no. 2474800 and after)

2шт.

2

A76551

LEVER

- shift, offset (Prior to transmission serial no. 2474800)

2шт.

3

B18208

SNAP RING,#100, Ext

shifter lever to shifter shaft #100, Ext

2шт.

5

A76552

SPRING

- wave, shifting lever

2шт.

6

A76307

OIL SEAL,25.4mm ID x 31.9mm OD x 4.75mm Thk

- oil, shifter shaft

2шт.

7

A58950

PIN

- retaining, shifter shaft

2шт.

8

A146850

LEVER

- shifter, third and fourth (Transmission serial no. 10027104 and after)

1шт.

9

A146849

LEVER

- shifter, first and second (Transmission serial no. 10027104 and after)

1шт.

10

A76549

LEVER

- shifter, third and fourth (Order A146850) (Prior to transmission serial no. 10027104)

1шт.

11

A76527

LEVER

- shifter, first and second (Order A146849) (Prior to transmission serial no. 10027104)

1шт.

12

A26530

SPRING

- detent, outer 13/32" OD x 1-1/2" long (10.32 x 38.1 MM)

2шт.

13

A23886

SPRING

- detent, inner 1/4" OD x 1-1/2" long (6.35 x 38.1 MM)

2шт.

14

211-12

BALL,7/16 Dia

- detent, 7/16" diameter (11.11 MM)

2шт.

15

A76524

FORK

- shifter, third and fourth

1шт.

16

A76523

FORK

- shifter, first and secoond

1шт.

17

138-58

LOCK PIN,1/8" x 13/16", Slotted

Pin, 1/8" x 13/16", Slotted

2шт.

18

A77136

RAIL

- shifter

1шт.

19

211-7

BALL,1/4" Dia

- shifter rail retainer (6.35 mm) 1/4" Dia

1шт.

20

A75171

SNAP RING,#112, 1.060", Ext

RING - snap, shifter rail retainer

1шт.

21

A138190

COLLAR

- sliding, shifting (Replaces A76692)

2шт.

22

A139078

SWITCH

- neutral start (Replaces A76403)

2шт.

23

G49402

SHIM,.010" Thk

Neutral start switch (0.2540 mm) .010" Thk

1шт.
