Запчасти Case IH FARMLIFT 935 (35.740.AE[01]) - BOOM CYLINDER (9M) (35) - HYDRAULIC SYSTEMS

1

47475513

HYDRAULIC CYLINDER

1шт.

2

47497365

PIN

1шт.

3

47487609

SPACER

1шт.

4

86625256

WASHER,13.3mm ID x 28.5mm OD x 4mm Thk

1шт.

5

11112431

SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd

1шт.

6

84578052

PLATE

2шт.

7

14422031

HEX SOC SCREW,M12 x 1.75 x 30mm, Cl 10.9, Full Thd

4шт.

8

84578696

PAD

2шт.

9

84578044

PAD

1шт.

10

9837786

HEX SOC SCREW,M12 x 20mm, Cl 8.8, Full Thd

2шт.

11

84382749

SCREW,BTN HD, M10 x 1.5 x 25mm, Cl 8.8

4шт.
