Запчасти Case IH FARMLIFT 935 (35.359.AE[08]) - CONTROL VALVE LINE, TILT SECTION, HYDRAULIC LINE (35) - HYDRAULIC SYSTEMS

1

84529614

HYD TUBE

Lift

1шт.

2

84529620

HYD TUBE

Lift

1шт.

3

9991976

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

2шт.

4

NSS

NOT SOLD SEPARAT

Connector, Incl in 6

2шт.

5

167266

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

2шт.

6

9840535

HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB

ASSY, Incl 3 - 5

2шт.

7

85802803

FITTING,9/16"-18 ORFS x 9/16"-18 ORB

ASSY, Incl 8, 9

2шт.

8

9825770

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

2шт.

9

NSS

NOT SOLD SEPARAT

Connector, Incl in 7

2шт.
