Запчасти Case IH 8581 (10-06) - WHEEL ASSEMBLY, CASTER Accumulator

1

T52730

WHEEL BOLT

9/16-18 WHEEL BOLT

24шт.

2

481344R91

WHEEL

14 X 8

4шт.

3

702700234

TIRE TUBE

TUBE 9.5L X 14

4шт.

4

425-1314

SLOTTED NUT,7/8"-14, G5

7/8-14 SHN

4шт.

5

26971

WASHER

4шт.

6

26690

HUB

ASSEMBLY (Includes Items 10 & 11)

4шт.

7

300426R91

BEARING ASSY,45.618 mm ID x 25.4 mm

BEARING - cone

4шт.

8

700113767

CASTER

WA

2шт.

9

491715R91

OIL SEAL

4шт.

10

130503H

BEARING CUP

BEARING - cup

4шт.

11

165964R1

BEARING CUP

BEARING - cup

4шт.

12

560953R91

BEARING ASSY,1.375" ID x 2.875" OD x 0.9688"

BEARING - cone

4шт.

13

432-824

COTTER PIN,1/8" x 1 1/2"

PIN, SPLIT (COTTER), 1/8" x 1-1/2"

4шт.

14

D143405

CAP

- hub

4шт.
