Запчасти Case IH 8581 (10-28) - CART ASSEMBLY, RIGHT Accumulator

1

121-226

SERRATED BOLT,Hex, 3/8" - 16 x 1"

8шт.

2

232-5316

FLANGE NUT,Flg, 3/8"-16

3/8-16 HFTLN GR/G

41шт.

3

6596274

SHOE (ASSY)

SHOE WA - skid

2шт.

4

700113807

FRAME

WA - right

1шт.

5

100-1675

SNAP RING,#75, Ext

Ring, Snap, #75, Ext

1шт.

6

95-81182

WASHER,0.81" ID x 1.25" OD x 0.07" Thk

3/4 X 14 GAUGE NRMB

2шт.

7

700716833

SPRING

- torsion

1шт.

8

434-412

CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 3/4", Gr 5

1/4-20 X 3/4 RHSNB

1шт.

9

496-11028

WASHER,9/32" x 5/8" x .065, HDN

1/4 HARDENED PLAIN WASHER

1шт.

10

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

11

425-104

NUT,1/4"-20, Cl 5

1шт.

12

751321

CLAMP

1/4 ID CLAMP

1шт.

13

700706340

MAGNET

1шт.

14

700113847

PAD

WA

1шт.

15

6810667

PIN

1шт.

16

432-1224

COTTER PIN,3/16" x 1-1/2"

3/16" x 1 1/2"

2шт.

17

700113846

LATCH

- cart, side

1шт.

18

413-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5

FTC Hex, 3/8"-16 x 1 1/4", G5, Full Thd

1шт.

19

425-106

NUT,3/8"-16, Cl 5

7шт.

20

7758956

SPRING

- torsion

1шт.

21

413-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5

8шт.

22

396-21066

WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk

- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN

8шт.

23

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

24

425-1010

NUT,5/8"-11, G5

8шт.

25

433-820

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 X 1-1/4 RHSNB

2шт.

26

231-5348

FLANGE NUT,Flg, 1/2"-13

1/2-13 HFTLN GR/G

2шт.

27

700113842

BAR

WA - weight

1шт.

28

700113809

PANEL

- cart, right

1шт.

29

433-612

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5

29шт.

30

433-620

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5

BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5

4шт.

31

6810394

RAIL

WA - guide, right

1шт.

32

700113851

COVER

BUBBLE

1шт.

33

434-612

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 3/4", Gr 5

3/8-16 X 3/4 RHSSNB

6шт.

34

492-11038

LOCK WASHER,3/8"

6шт.

35

409-7612

BOLT,3/8"-16 x 1.09" OAL

3/8-16 X 3/4 HWHMS

1шт.
