Запчасти Case IH 8576 (05-010) - CRANK DRIVE AND MOUNTING ASSEMBLY, S.N. CFH0113001 THRU CFH0163128 (16) - BALE EJECTOR

1

433-820

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5

8шт.

2

80679

LOCK WASHER,1/20.507 CST ZND

8шт.

3

425-108

NUT,1/2" - 13, Gr 5

8шт.

4

51318

BEARING

spherical

1шт.

5

50583

FLANGED BEARING

BEARING

2шт.

6

616154R92

BEARING, ROLLER, CYL,16 mm

cylindrical

4шт.

7

700124038

BUSHING,16.27mm ID x 34.92mm OD x 10mm L

BEARING

8шт.

8

700124036

LINK CONROD

ASSEMBLY, Includes: Ref. 6

2шт.

9

52548

SPECIAL WASHER

2 x 14 gauge, NRMB

6шт.

10

714360

FLANGED BEARING

2шт.

11

740407

BRUSH, COMMUTATOR

BRUSH 2 x 10 gauge, NRMB

2шт.

12

700123418

SPROCKET ASSY.

tooth, WA 80C35

1шт.

13

700113661

NUT

stake, 1-5/8-12

1шт.

14

712158

SPHERICAL BEARING,2" ID x 100 mm OD

spherical

1шт.

15

700113666

SPACER

1шт.

16

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8-11 x 2-1/4 C

4шт.

17

232-41110

NUT,5/8"-11, GC

4шт.
