Артикул
Название
Примечание
Количество
1
H674500
VALVE
Backhoe, See Figures 8-56 - 8-68
1шт.
2
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
Incl. Ref 3
3шт.
3
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
Part of P/N 218-5059
1шт.
4
H439269
ELBOW
Includes: Ref. 5
1шт.
5
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
Part of P/N H439269
1шт.
6
H438685
HOSE
3600 mm (141-7/8 in)
1шт.
7
H438227
HOSE
3700 mm (145-3/4 in)
1шт.
8
H674567
PIPE,12.7 mm OD x 597 mm L
1шт.
9
1346397C2
CYLINDER ASSY.
70 ID x 559 mm strk, Bucket, See Figure 8-72
1шт.
10
214-1456
HOSE CLAMP,#56, 3.06" - 4", Type F Worm
3-1/16 - 4 in dia
1шт.
11
D132054
SLEEVE
1шт.
12
H439063
SLEEVE
1шт.
13
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP 15 in
3шт.
Выбрано товаров: 15
