Запчасти Case IH 90XT (06-25) - MOTOR ASSEMBLY (06) - POWER TRAIN

192899A2

MOTOR, HYDRAULIC

Consists Of: 6-24, 6-25, No Longer Available, Order 192899A3

2шт.

192899A3R

REMAN-HYD MOTOR

Reman For New Part PN 192899A2

2шт.

192899A3C

CORE-MOTOR HYDRAULIC

Return Number

2шт.

192899A3

MOTOR, HYDRAULIC

Consists Of: 6-24, 6-25

2шт.

192899A3R

REMAN-HYD MOTOR

90XT CASE SKID STEER LOADER

2шт.

192899A3C

CORE-MOTOR HYDRAULIC

Return Number

2шт.

1

234734A1

PLUG

1шт.

2

100-21156

SNAP RING,1.562", Int, #156

1шт.

3

H438288

SEAL

1шт.

4

106564A1

SCREW

4шт.

5

259498A1

PLUG

Includes: Ref. 6

2шт.

6

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

7

106548A1

SPRING

2шт.

8

106547A1

GUIDE

2шт.

9

106546A1

SPOOL

1шт.

10

294932A1

PORT

1.93 mm, Used With 192899A2

1шт.

10a

234396A1

PORT

used With 192899A3, Not Illustrated

1шт.

11

132391A1

BEARING, NEEDLE

1шт.

12

124826A1

GASKET

1шт.
