Запчасти Case IH 75XT (08-11) - HYDRAULICS - COUPLER SYSTEM (08) - HYDRAULICS
№
Артикул
Название
Примечание
Количество
Gear Pump to Hose Mounting Bracket
1шт.
North American Models JAF0318922-
1шт.
European Models JAF0452169-
1шт.
1
L11541
CABLE TIE,203.2mm L, Nylon
CABLE STRAP
1шт.
2
394910A1
HARNESS
Flyback Diode Jumper
1шт.
3
187505C91
VALVE
See Figure 08-24
1шт.
4
218-5057
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
Incl. 5
2шт.
6
218-5105
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
9/16 fl x adj Or, Includes 7
1шт.
8
277781A1
LARGE PLATE
PLATE, LARGE
1шт.
9
811-6060
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 60mm, Cl 8.8
6 x 60 mm
2шт.
10
376352A1
TEE
.952 mm (3/8 in), Includes 13
1шт.
12
430304A1
HOSE ASSY.
1340 mm (52-3/4 in)
1шт.
13
218-766
REDUCER,37 Degree, 1 1/16"-12, Fem x 9/16"-18 Male
3/4 x 3/8
1шт.
14
399942A2
HOSE ASSY.
1700 mm (66-7/8 in), For Attaching Parts, See Figure 08-12, REF 22
1шт.
15
218-1254
LOCK NUT,Blkhd, 9/16"-18
2шт.
16
218-693
ELBOW,90 Degree Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree
1шт.
17
399937A2
TUBE
Coupler Valve
1шт.
18
399943A2
HOSE ASSY.
1780 mm (70 in), For Attaching Parts, See Figure 08-12, REF 21
1шт.
19
218-673
FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree
FIT STL BULKHD .375MJ .375MJ
1шт.
20
419783A1
TUBE
Coupler Valve
1шт.
21
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP 15 in
1шт.
22
832-41408
NUT,M8 x 1.25, Cl 10
M8
2шт.
23
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
4шт.
24
614-8020
BOLT,Hex, M8 x 1.25 x 20mm
2шт.
25
276726A1
SUPPORT
1шт.
26
515-22127
CLAMP,1/2", Insul, 5/16" Bolt
2шт.
27
429851A1
HOSE ASSY.
550 mm (21-5/8 in)
1шт.
28
399945A1
HOSE ASSY.
2185 mm (86 in)
1шт.
29
259347A1
HARNESS
Hydraulic Coupler, See Figure 04-11
1шт.
5
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
7
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
11
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
Выбрано товаров: 32
