Артикул
Название
Примечание
Количество
1
NSS
NOT SOLD SEPARAT
FRAME upright
1шт.
2
D63894
PIN
retaining
4шт.
3
26-636
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 8
hex head, 3/8" - 16 NC x 2-1/4", grade 8
4шт.
4
131-652
LOCK NUT,3/8"-16, GB
NUT hex, self lock, 3/8" - 16 NC
4шт.
5
REF
INSTRUCTION
CYLINDER lift, parts list Figure 218
2шт.
6
D70475
ARM
self leveling, without auxiliary hydraulics
2шт.
6
D63689
ARM
self leveling, with auxiliary hydraulics, Includes Ref. 7
2шт.
7
D51608
BUSHING,25.63mm ID x 34.92mm OD x 25.4mm L
D70475 and D63689 arm
4шт.
8
D63895
PIN
lift, Serial Range: arm-upright
2шт.
9
195-2121
WASHER,1 5/16" x 2" x .065"
flat
1шт.
11
131-652
LOCK NUT,3/8"-16, GB
NUT hex, self lock, 3/8" - 16 NC
2шт.
12
D90319
ARM, LIFT
ARM lift, Includes Ref. 13-14
1шт.
13
D33827
BUSHING,31.98mm ID x 41.27mm OD x 31.8mm L
1-1/4", 31.75 mm ID
8шт.
14
D51608
BUSHING,25.63mm ID x 34.92mm OD x 25.4mm L
1", 25.4 mm ID
4шт.
15
D68829
PIN
retaining
6шт.
16
26-636
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 8
hex head, 3/8" - 16 NC x 4-1/4", grade 8
6шт.
17
131-652
LOCK NUT,3/8"-16, GB
NUT hex, self lock, 3/8" - 16 NC
6шт.
18
195-2105
WASHER,1 1/16" x 1 3/4" x .065"
flat
1шт.
19
D67387
PIN
lift cylinder retaining
1-2шт.
20
26-636
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 8
hex head, 3/8" - 16 NC x 2-1/4", grade 8
2шт.
21
131-652
LOCK NUT,3/8"-16, GB
NUT hex, self lock, 3/8" - 16 NC
2шт.
22
D63639
PLATE
self leveling, inner
2шт.
23
D63638
PLATE
self leveling, left hand outer
1шт.
24
D63783
PLATE
self leveling, right hand outer
1шт.
25
G34926
CYLINDER
bucket, parts list Figure 220
2шт.
118156A1R
1845 - CASE UNI-LOADER SKID STEER LOADER (NORTH AMERICA), 1845S - CASE UNI-LOADER SKID STEER LOADER; Reman for new P/N G34926
REMAN-HYD CYLINDER
2шт.
118156A1C
Return Number
CORE-HYD CYLINDER
1шт.
26
RESERVED
1шт.
27
219-1
LUBE NIPPLE,1/8" - 27 NPTF
GREASE FITTING straight, 1/8" NPT
8шт.
28
D68783
ROD
indicator
1шт.
29
D68782
ELECTRICAL GAUGE
GAUGE sight, bucket
1шт.
30
214-264
HOSE CLAMP,#52, 2.81" - 3.75", Type F Worm
CLAMP worm screw type
2шт.
31
D38648
BLOCK
CUSHION rubber
2шт.
32
D63633
BLOCK
stop
4шт.
33
D68960
STOP
SUPPORT strut
2шт.
34
D63534
PIN
stop
4шт.
35
136-159
HAIR PIN COTTER,Int, 3/16 x .080"
PIN, SPLIT (COTTER), Int, 3/16 x .080"
8шт.
36
D87884
STAY
STRUT support, lift arm, used on models with support strut
1шт.
37
D89804
STRIP
rubber, strut, used on models with support strut
1шт.
38
D79692
PAD
lift arm, used on models with support strut
2шт.
38
D79998
PIN
strut, used on models with support strut
1шт.
40
136-159
HAIR PIN COTTER,Int, 3/16 x .080"
PIN, SPLIT (COTTER), , Used on models with support strut Int, 3/16 x .080"
1шт.
41
D25277
SNAP RING,23.5mm ID x 2.62mm Thk
RETAINING RING, used on models with support strut
2шт.
42
D87883
PIN
strut, lift cylinder retaining, used on models with support strut
1шт.
43
345-67
GLUE
ADHESIVE not shown, used on models with support strut
1шт.
Выбрано товаров: 46
