1
87416017
PUMP
Replaces J928143
1шт.
2
221-841
PLUG
1/4 PT
1шт.
3
J939258
GASKET,1.21mm Thk
Mounting; Replaces J931059
1шт.
4
845-8025
BOLT,Hex Flg, M8 x 25mm, Cl 8.8
2шт.
5
J905649
FUEL TUBE,8 mm OD x 233.5 mm L
1шт.
6
J903035
BANJO BOLT
M12 x 24
1шт.
7
87415913
SEALING WASHER,11.71mm ID x 19.3mm OD x 1.27mm Thk
12 mm; Replaces J918191, J935171
4шт.
8
J918640
FUEL TUBE
Incl. 9, 10
1шт.
9
222-103
SLEEVE,5/16" Tube
2шт.
10
222-4
FITTING,9/16"-24, Flex Tube
5/16 OD
1шт.
J905860
BANJO BOLT
Incl. 11, 12
1шт.
11
J911446
BANJO BOLT,M12 x 1.5 x 24mm
1шт.
12
J939570
BLEED SCREW,Hex, M6 x 1 x 10mm, Cl 8.8
M6 x 10
1шт.
13
J909695
FUEL TUBE
Incl. 13A
1шт.
13a
222-101
SLEEVE,3/16" Tube
1шт.
14
222-121
TEE,3/16", Flex Tubing
1шт.
15
J905699
FUEL TUBE,4.76 mm OD
Incl. 15A
1шт.
15a
222-101
SLEEVE,3/16" Tube
1шт.
16
J905692
FUEL TUBE
Incl. 16A
1шт.
16a
222-101
SLEEVE,3/16" Tube
1шт.
18
J905307
BANJO BOLT,M6 x 1 x 14.30mm
4шт.
19
J903380
SEAL
4шт.
20
J935213
INJECTOR ASSY.
See Fig 03-13, 03-14
4шт.
20
JR935213
REMAN-FUEL INJECTOR
REMANUFACTURED INJECTION NOZZLE
4шт.
20
JC935213
CORE-FUEL INJECTOR
Return Number, INJECTION NOZZLE
4шт.
21
J923261
WASHER,7.2mm ID x 15mm OD x 2.5mm Thk
2.5 mm; See Fig 03-13, 03-14
4шт.
22
J935691
FUEL TUBE,1.8 mm ID x 6.35 mm OD x 750 mm L
No. 1
1шт.
23
J935693
FUEL TUBE,1.8 mm ID x 6.35 mm OD x 750 mm L
No. 2
1шт.
24
J935696
FUEL TUBE,1.8 mm ID x 6.35 mm OD x 750 mm L
No. 3
1шт.
25
J935698
FUEL TUBE,1.8 mm ID x 6.35 mm OD x 750 mm L
No. 4
1шт.
26
CURJ904711
CLAMP
8шт.
27
J907546
BRACE
4шт.
28
J917746
CLAMP
16шт.
29
J920854
CAPTIVE WASHER SCREW,HWH, M5 x 0.8 x 24.5mm, Cl 8.8
8шт.
30
J935746
BRACE
2шт.
31
J935748
BRACE
1шт.
32
J935700
BRACE
1шт.
33
J928759
SEALING WASHER
4шт.
34
844-8016
BOLT,Hex, M8 x 16mm, Cl 8.8
Replaces 845-8016
4шт.
35
J925955
ADAPTER,M16 x 1.5 x M16 x 1.5
1шт.
36
J931062
FILTER
Fuel; No Longer Available, Order J286503
1шт.
36
J286503
FUEL FILTER
1шт.
