Артикул
Название
Примечание
Количество
1
125091A1
CABLE
- throttle control, no longer available, for service, order items 1 and 1A on Fig. 3-07A, diesel models
1шт.
2
463-11010
SCREW,Hex Hd, #10-24 x 5/8"
- machine, hex head, No. 10 NC x 5/8 inch, diesel models
2шт.
3
193-1004
NUT,Keps, #10 - 24, w/ Ext Tooth LW
NUT - hex, with external tooth lock washer, No. 10 NC, diesel models
2шт.
4
D92852
PIVOT
STOP - throttle cable, diesel models
1шт.
5
432-68
COTTER PIN,3/32" x 1/2"
PIN, SPLIT (COTTER), , Diesel models 3/32" x 1/2"
1шт.
6
104039A1
CABLE ASSY.
CABLE - fuel shut-off (replaces D122111), diesel models
1шт.
7
D91273
KNOB
- fuel shut-off cable, diesel models
1шт.
8
L32208
CLAMP
STOP - fuel shut-off cable, diesel models
1шт.
9
470-1108
SCREW,Slotted Pan Hd, #10-24 x 1/2"
- machine, pan head slotted, No. 10 NC x 1/2 inch, diesel models
4шт.
10
351100C1
CLAMP
- cables, diesel models
2шт.
11
D122051
PLATE
- cables, diesel models
1шт.
12
193-1004
NUT,Keps, #10 - 24, w/ Ext Tooth LW
NUT - hex, with external tooth lock washer, No. 10 NC, diesel models
4шт.
13
L18337
CABLE TIE,9.95"-12.1" lg
STRAP - tie, 15 inch, nylon, diesel models
1шт.
14
121831A1
LARGE PLATE
BRACKET - throttle limit plate, was H438528, diesel models
1шт.
15
495-31022
WASHER,#10
Diesel models #10
2шт.
16
E20622
CABLE
- throttle control, no longer available for service, order items 16 and 16A on Fig. 3-07A, gasoline models
1шт.
17
463-11010
SCREW,Hex Hd, #10-24 x 5/8"
- machine, hex head, No. 10 NC x 5/8 inch, gasoline models
2шт.
18
193-1004
NUT,Keps, #10 - 24, w/ Ext Tooth LW
NUT - hex, with external tooth lock washer, No. 10 NC, gasoline models
2шт.
19
D92852
PIVOT
- throttle cable, gasoline models
1шт.
20
432-68
COTTER PIN,3/32" x 1/2"
PIN, SPLIT (COTTER), , Gasoline models 3/32" x 1/2"
1шт.
21
E20293
BRACKET
- throttle cable mounting, use existing lower mounting bolt for governor, was D137826, gasoline models
1шт.
22
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
(Flat, 13/32 x 13/16 x 1/16"), Gasoline models 3/8", SAE
1шт.
23
463-11010
SCREW,Hex Hd, #10-24 x 5/8"
- machine, hex head, No. 10 NC x 5/8 inch, gasoline models
2шт.
24
351100C1
CLAMP
- throttle cable, gasoline models
1шт.
25
193-1004
NUT,Keps, #10 - 24, w/ Ext Tooth LW
NUT - hex, with external tooth lock washer, No. 10 NC, gasoline models
2шт.
26
D91274
KNOB
- choke control cable, gasoline models
1шт.
27
104041A1
CABLE ASSY.
CABLE - choke (replaces D137836), gasoline models
1шт.
28
L18337
CABLE TIE,9.95"-12.1" lg
STRAP - tie, 15 inch, nylon, gasoline models
1шт.
29
137272A1
LARGE PLATE
BRACKET - throttle limit plate, was H438528, gasoline models
1шт.
30
495-31022
WASHER,#10
Gasoline models #10
2шт.
Выбрано товаров: 30
