Запчасти Case IH 1816 (74) - D56774 LOADER LIFT CYLINDER, WARD CYLINDER, NO SPUDS AT HYDRAULICS PORTS (35) - HYDRAULIC SYSTEMS

D56774

CYLINDER

hydraulic, lift, 2" I.D. x 27" stroke, service with D58575 cylinder and D60509 tube, Includes: Ref. 1 - 17

2шт.

1

D59087

SCREW set

1шт.

2

D59086

CAP retaining, gland

1шт.

3

D59365

ROD piston, 1" diameter

1шт.

4

D59081

BOX

GLAND packing

1шт.

5

D59363

SPACER piston

1шт.

6

D59079

PISTON split, outer

1шт.

7

D59361

PISTON split, inner

1шт.

8

131-91

LOCK NUT,3/4"-16, G8

NUT hex, lock

1шт.

D59366

KIT

packing, Includes: Ref. 9 - 16

1шт.

9

D59085

SEAL ASSY.

WIPER rod, outer

1шт.

10

D59084

RING

WIPER rod, inner

1шт.

11

D59083

RING

backup, gland seal

1шт.

12

D32127

O-RING

SEAL "o"ring, gland

1шт.

13

D59076

PACKING

piston

2шт.

14

T13224

O-RING,1.484" ID x 1.762" OD x 0.139"

SEAL piston, large

1шт.

15

A27365

O-RING,0.103" Thk x 0.75" ID, -116, Cl 5, 75 Duro

SEAL piston, small

1шт.

16

D59362

BEARING

piston

1шт.

17

D59364

TUBE cylinder

1шт.
