Артикул
Название
Примечание
Количество
1
T42290
SPARE PART BLOCK - hydraulic cushion
1шт.
2
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
2шт.
3
92-5
LOCK WASHER,5/16"
2шт.
4
T41973
SPARE PART Angle
1шт.
5
D55812
LINING
PIN - clevis
1шт.
6
D55811
CLIP
PIN - hair
2шт.
7
D55812
LINING
PIN - clevis
1шт.
8
D54490
HOSE ASSY.
Hydraulic (74" long)
2шт.
9
T41332
COUPLING, BREAK AWAY
Quick disconnect, male
2шт.
10
D54516
SPARE PART Retaining, bracket
1шт.
11
D54517
SPARE PART Retaining chain
1шт.
12
13-680
CAPSCREW,Hex, 3/8" - 16 x 5", Gr 5
4шт.
13
92-6
LOCK WASHER,3/8"
4шт.
14
25-106
NUT,3/8"-16, G5
4шт.
15
T42307
CHAIN (AG)
Retaining
1шт.
16
T41977
TURNBUCKLE
ASSEMBLY - complete
1шт.
17
T42289
LARGE PIN
PIN, LARGE Clevis, 1/2" x 1-3/4"
1шт.
18
132-48
COTTER PIN,1/8" x 1"
1шт.
19
T41978
MOUNTING - caster bracket
2шт.
21
13-816
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
8шт.
22
92-8
LOCK WASHER,1/2"
8шт.
23
95-8
WASHER,1/2"
8шт.
24
T41979
CASTER
ASSEMBLY - complete
2шт.
25
13-820
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd
HHCS - 1/2" - 13 NC x 1"
8шт.
26
92-8
LOCK WASHER,1/2"
8шт.
27
25-108
NUT,1/2"-13, G5
8шт.
28
NSS
NOT SOLD SEPARAT
HOOD - rear
1шт.
29
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
3шт.
30
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
4шт.
31
95-5
WASHER,3/8" x 7/8" x .083"
WASHER - plain, 5/16"
7шт.
32
92-5
LOCK WASHER,5/16"
7шт.
33
9635082
NUT,5/16" - 18, Gr 5
3шт.
34
T41980
SPACER
Shaft, short
1шт.
35
218-903
HYD CONNECTOR,1/2" NPT x 1/2"
ADAPTER - straight, adjustable
2шт.
36
T41971
HOSE ASSY.
Hydraulic
2шт.
37
221-1093
REDUCER,Hex, 3/4" x 1/2" NPT
Pipe
2шт.
38
T41981
BEARING
Shaft
2шт.
39
13-716
BOLT,Hex, 7/16" - 14 x 1", Gr 5
4шт.
40
92-7
LOCK WASHER,7/16"
4шт.
41
T41982
BUSHING
SPACER - shaft, long
1шт.
42
T41984
SPARE PART Drive
1шт.
43
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
6шт.
44
92-6
LOCK WASHER,3/8"
6шт.
45
B12501
LINK
Connecting, #40 chain
1шт.
REF
INSTRUCTION
CHAIN - roller (119 links, #40 chain) Use (2) B12470, (1) B12472, (1) B12501, (4) B12502, (4) B12503
1шт.
46
B12470
CHAIN (AG)
LINK - roller (50 links, #40 chain)
2шт.
47
B12472
CHAIN (AG)
LINK - roller (10 links, #40 chain)
1шт.
48
B12502
OFFSET LINK
#40 chain
4шт.
49
B12503
ROLLER
LINK, #40 chain
4шт.
50
RESERVED
1шт.
51
NSS
NOT SOLD SEPARAT
FRAME - broom
1шт.
52
T42306
AXLE PIN
Pivot, post
1шт.
53
132-91
COTTER PIN,3/16" x 1"
2шт.
54
T42304
SPARE PART Motor retainer
1шт.
55
T42303
SPARE PART Motor adjusting
1шт.
56
85-648
SCREW - set, sq. hd. (3/8" - 16 NC x 3")
1шт.
57
25-106
NUT,3/8"-16, G5
2шт.
58
T42305
SPARE PART Chain
1шт.
59
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
1шт.
60
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
1шт.
61
95-5
WASHER,3/8" x 7/8" x .083"
WASHER - plain, 5/16"
2шт.
62
92-5
LOCK WASHER,5/16"
2шт.
63
9635082
NUT,5/16" - 18, Gr 5
2шт.
64
83-56
SET SCREW,Hex Soc, 5/16"-18 x 3/8"
(5/16" - 18 NC x 1-3/8")
2шт.
65
T41987
DRIVE SPROCKET
Motor
1шт.
66
P2712S
SPARE PART Sprocket
1шт.
67
T41963
MOTOR, ELECTRIC
Hydraulic (Parts list Figure 224)
1шт.
68
13-728
BOLT,Hex, 7/16" - 14 x 1-3/4", Gr 5
4шт.
69
92-7
LOCK WASHER,7/16"
4шт.
70
25-107
NUT,7/16"-14, G5
4шт.
71
NSS
NOT SOLD SEPARAT
HOOD - front
1шт.
72
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
3шт.
73
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
3шт.
74
95-5
WASHER,3/8" x 7/8" x .083"
WASHER - plain, 5/16"
6шт.
75
92-5
LOCK WASHER,5/16"
6шт.
76
9635082
NUT,5/16" - 18, Gr 5
3шт.
77
T31049
SPARE PART Clip
2шт.
78
T41965
PIN
Mounting, adapter
2шт.
79
NSS
NOT SOLD SEPARAT
FRAME - yoke
1шт.
80
T42288
CLEVIS COUPLING
1/2" x 1-1/4"
1шт.
81
132-48
COTTER PIN,1/8" x 1"
1шт.
82
T41964
WASHER
RING - pivot, upper
1шт.
83
13-640
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
1шт.
84
92-6
LOCK WASHER,3/8"
1шт.
85
95-6
WASHER,3/8"
1шт.
86
D40236
CLAMP
1шт.
87
D33554
BUSHING
SPACER - hose clamp
1шт.
88
25-106
NUT,3/8"-16, G5
1шт.
89
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
3/8" - 16 NC x 1/2"
1шт.
90
92-6
LOCK WASHER,3/8"
1шт.
91
D54744
SPARE PART Clamp mounting (Standard arms only)
1шт.
92
T41967
SPARE PART CORE - brush, round (When stock is exhaused, use D54278 core), angle broom with keystrand core only
1шт.
93
D54278
SPARE PART Brush, round, angle broom with keystrand core only
1шт.
94
T41969
WHEEL
SPACER - brush, angle broom with keystrand core only
35шт.
95
T41986
CYLINDER END CAP
Angle broom with keystrand core only
1шт.
96
T41968
BRUSH
DISC, angle broom with keystrand core only
36шт.
97
T41966
BROOM - palmyra, angle with core only
1шт.
Выбрано товаров: 98
