Запчасти Case IH 1530 (040) - FRONT AXLE ASSEMBLY WITH BRAKES (06) - POWER TRAIN

1

F23214

WHEEL NUT

Wheel, special

12шт.

D53771

SPARE PART ASSEMBLY - with bolts, Includes Ref. 2 - 3

2шт.

2

NSS

NOT SOLD SEPARAT

AXLE - wheel

1шт.

3

T40045

WHEEL BOLT

Wheel, special

6шт.

4

D53767

OIL SEAL,57.15mm ID x 85.75mm OD x 11mm Thk

Oil

2шт.

5

D53766

TAPERED BEARING,1.7812" ID x 0.78"

CONE

4шт.

D53763

HUB

ASSEMBLY - axle, Includes Ref. 6 - 7

2шт.

6

NSS

NOT SOLD SEPARAT

HUB - axle

1шт.

7

D53762

BEARING CUP,2.892" OD x 0.62"

Bearing

2шт.

8

D53784

BUSHING

SPACER - axle

2шт.

9

D53024

DRIVE SPROCKET

Front axle

2шт.

10

T42395

GASKET

Hub

2шт.

11

S75790

RING

Snap

2шт.

12

D53834

BEARING

Ball

2шт.

13

D53835

SEAL

Oil

2шт.

14

D53720

HUB CAP

Axle, brake band mounting

2шт.

15

D53775

SEAL ASSY.

Oil

2шт.

16

D53273

WASHER,23.02mm ID x 57.15mm OD x 1.41mm Thk

Special

2шт.

17

25-1314

SLOTTED NUT,7/8"-14, G5

2шт.

18

132-52

COTTER PIN,1/8" x 1 1/2"

2шт.

19

92-9

BEARING WASHER,9/16"

16шт.

20

25-119

NUT,9/16"-18, G5

16шт.

21

D53743

SPARE PART Backing, brake mounting

2шт.

22

D53721

SPARE PART Brake mounting, LH

1шт.

23

D53722

BLOCK

Brake mounting, RH

1шт.

24

61-836

BOLT,1/2" - 13 x 2 1/4"

Hex, sprocket head (1/2" - 13 NC x 2-1/4")

10шт.

25

A29912

BOLT

Special, Serial Range: drum-block

10шт.

26

D53792

SPARE PART Brake (When stock is exhausted, use D55966 drum)

2шт.

26

D55966

DRUM HUB

Brake

2шт.

27

14-1020

BOLT,Hex, 5/8" - 18 x 1-1/4", Gr 5

6шт.

28

REF

INSTRUCTION

BRAKE ASSEMBLY - see Fig. 42 for mounting and component parts

2шт.
