Запчасти Case IH 1529 (147A) - CONTROL VALVE STARTING FROM UP TO 3755880

D53433

VALVE

control ass'y, Includes: Ref. 1 - 30

1шт.

1

36645

CAP

BONNET rubber

3шт.

2

36633

LID

snap

3шт.

3

663023R1

CAP

3шт.

4

75-48

SCREW,Rd, 1/4" - 20 x 1/2"

BOLT

3шт.

5

36628

LOCK WASHER

lock ext. shakeproof

3шт.

6

36630

DRAWBAR SUPPORT

stop

3шт.

7

36632

SPRING

3шт.

8

36650

WASHER

3шт.

9

NSS

NOT SOLD SEPARAT

HOUSING

1шт.

10

NSS

NOT SOLD SEPARAT

SPOOL

3шт.

11

34109

SPARE PART NUT acorn

1шт.

12

34111

X

NUT jam

1шт.

13

34110

ADJUSTMENT SCREW

1шт.

14

34113

BODY

1шт.

15

36660

WASHER

1шт.

16

34114

VALVE, PRESSURE RELI

EF SPRING

1шт.

17

CAS34120

BUSHING

SPACER

1шт.

18

211-12

BALL,7/16 Dia

1шт.

19

D46222

SEAT

1шт.

20

D28576

VALVE POPPET

2шт.

21

D28574

PLUG

1шт.

T42174

GASKET KIT

seal, Includes: Ref. 22 - 26

1шт.

22

T42095

O-RING

SEAL

6шт.

23

A29197

O-RING,0.424" ID x 0.63" OD x 0.103"

SEAL

1шт.

24

34115

GASKET

SEAL

1шт.

26

D48359

O-RING,0.103" Thk x 0.549" ID, -113, Cl 6, 90 Duro

Seal

1шт.

27

D54293

SLEEVE CYLINDER

1шт.

28

D48086

SEAL,1.358" ID

SEAL

1шт.

29

D53169

RING

SEAL

1шт.

30

36640

DRAG LINK

ASSY handle

3шт.

31

132-13

PIN

cotter

3шт.

25

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

Seal

1шт.
