Запчасти Case IH SV300 (29.200.AI[04]) - ELECTRONIC CONTROLS, HANDLE MOUNTING (29) - HYDROSTATIC DRIVE

Схема запчастей Case IH SV300 - (29.200.AI[04]) - ELECTRONIC CONTROLS, HANDLE MOUNTING (29) - HYDROSTATIC DRIVE
90.150.ab
4
1
5
6
2
8
3
7
55.512.cl 03
90.160.as 01
29.200.ai 05

Артикул

Название

Примечание

Количество

1

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

4шт.

2

47544570

IMPORTANT DECAL

EZ EH Operation

1шт.

3

47619265

247.2mm L, Heel Cover

PLATE

1шт.

4

47710379

SCREW,Pan Head, M5 x 0.8, Full Thd, Cl 4.8

4шт.

5

84322854

684mm L, Sealing Strip

FOAM INSULATION,684mm L x 6mm W x 3mm Thk

1шт.

6

86512497

FLANGE NUT,M12 x 1.75, Cl 10

1шт.

7

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

4шт.

8

86598598

CLAMP,19mm, Insulated, 13.5mm Bolt Hole - P Type

1шт.

Выбрано товаров: 8
