Запчасти Case IH SV300 (55.512.BQ[02]) - INSTRUMENT CLUSTER & IGNITION SWITCH, KEYLESS (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH SV300 - (55.512.BQ[02]) - INSTRUMENT CLUSTER & IGNITION SWITCH, KEYLESS (55) - ELECTRICAL SYSTEMS
5
2
3
1
4
4

Артикул

Название

Примечание

Количество

1

47558626

Deluxe

INSTRUMENT CLUSTER

1шт.

2

84270680

Key Blank

DECAL

1шт.

3

1964831C2

IGNITION KEY

Ignition Switch and Door, Padded, Case Logo

1шт.

4

86511042

SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8

Instrument Cluster Mounting

2шт.

5

87000312

CABLE TIE,4.8mm W x 203.2mm OAL, Nylon

1шт.

Выбрано товаров: 5
