(10.414.AD[03]) - FAN BELT EU SLOW SPEED CRANKSHAFT PULLEY

Запчасти Case IH SR200 (10.414.AD[03]) - FAN BELT EU SLOW SPEED CRANKSHAFT PULLEY (10) - ENGINE

Схема запчастей Case IH SR200 - (10.414.AD[03]) - FAN BELT EU SLOW SPEED CRANKSHAFT PULLEY (10) - ENGINE
4
home
2
3
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

9515003

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9

6шт.

2

47615375

Crankshaft, F5C, Fan EURO

PULLEY

1шт.

3

47615376

V-BELT,21.66mm W x 1469mm L, 6 Ribs

1шт.

4

86625253

WASHER,11mm ID x 24mm OD x 2mm Thk

6шт.
