(55.404.CY[02]) - EU REAR LIGHT, ROAD LIGHT

Запчасти Case IH SR175 (55.404.CY[02]) - EU REAR LIGHT, ROAD LIGHT (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH SR175 - (55.404.CY[02]) - EU REAR LIGHT, ROAD LIGHT (55) - ELECTRICAL SYSTEMS
8
7
4
2
1
1
8
3
6
4
7
5
7
3
home
7
2
6
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

4шт.

2

86502967

SCREW,Phillips Drive, Pan HD, M5 x 30mm, Cl 4.8

8шт.

3

86512420

CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8

4шт.

4

86512495

FLANGE NUT,Hex, M5, Cl 8

8шт.

5

87627854

LIGHT ASSY.,12V, 27W, Red

Rear Stop, Tail Lamp, Incl 7

2шт.

6

87629587

LIGHT ASSY.,12V, 27W, Amber

Turn Signal Lamp/Flasher Lamp, Incl 7

2шт.

7

87642985

BULB,3157, 12V, 26.5W, Clear

4шт.

8

47870827

BRACKET

Rear Road Lights, Tan

2шт.
