Запчасти Case IH 4155 (12-01) - POWER, ENGINE & MOUNTING (04) - Drive Train

Схема запчастей Case IH 4155 - (12-01) - POWER, ENGINE & MOUNTING (04) - Drive Train

Артикул

Название

Примечание

Количество

1

119292

COUPLING, 3/8 to 1/8 pln pipe

1шт.

2

221-106

PIPE,Nipple, 1/8" NPT x 1 1/2"

NIPPLE, 1/8 x 1-1/2 pln long pipe

2шт.

3

NSS

NOT SOLD SEPARAT

HOSE, tank to separator, Use 48 in. from 50 ft. roll marked 180730C1

1шт.

27861R1

HOSE CLAMP,#10, .56/1.06 Type F Worm, W/liner

CLAMP, no. 10 shoe type F hose

2шт.

4

NSS

NOT SOLD SEPARAT

HOSE, fuel return, Use 72 in. from 50 ft. roll marked 180730C1

1шт.

27861R1

HOSE CLAMP,#10, .56/1.06 Type F Worm, W/liner

CLAMP, no. 10 shoe type F hose

2шт.

5

79387C1

SUPPORT, motor, Lower

1шт.

6

79396C1

FITTING, barb

2шт.

7

9410201

HYD CONNECTOR,1/2"-20, 37 Degree x 1/2"-20, O-Ring

CONNECTOR, 5/16 C-Z hyd fld short SW

2шт.

8

NSS

NOT SOLD SEPARAT

HOSE, separator to fuel pump, Use 11 in. from 50 ft. roll marked 180730C1

1шт.

27861R1

HOSE CLAMP,#10, .56/1.06 Type F Worm, W/liner

CLAMP, no. 10 shoe type F hose

2шт.

9

79388C91

FILTER, water separator

1шт.

79389C1

HEAD, filter

1шт.

79390C1

O-RING

1шт.

79391C1

WASHER

1шт.

79392C1

ELEMENT

1шт.

79393C1

CLAMP

1шт.

79394C1

SCREW

1шт.

79395C1

PLUG

1шт.

10

74761C1

FITTING

1шт.

11

73855C1

BOLT,5/8" - 11 x 5 1/2"

J

2шт.

NLS

NO LONGER SERVICED

.656 x 1.312 x .074

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8 type 5

2шт.

12

77590C1

SENDER UNIT

GAUGE, oil pressure sender

1шт.

13

105416

TEE,1/8" NPT, Fem

1/8 pln pipe

1шт.

14

72246C1

SWITCH

oil pressure shut-off

1шт.

15

78163C1

NIPPLE, 1/8 x 1-1/2 special

1шт.

16

79397C1

SUPPORT, rear motor

1шт.

180177

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5

1/2 x 1-1/2 type 5

4шт.

120384

WASHER,1/2"

LOCK, 1/2"

4шт.

120387

WASHER,3/8" x 3/4" x .060"

.375 x .750 x .054

4шт.

17

79349C1

HOSE, radiator

2шт.

27724R1

HOSE CLAMP,#24, 1.06/2.00 Type F Worm, W/liner

CLAMP, no. 24 shoe type F hose

4шт.

18

72157C1

WASHER, retainer

4шт.

19

72158C1

MOUNT, motor

8шт.

20

72159C1

BUSHING

4шт.

180192

BOLT (SPREADER),Hex, 1/2" - 13 x 3 1/2", Gr 5

BOLT, 1/2 x 3-1/2 type 5

4шт.

9413967

LOCK NUT,1/2"-13, GB

NUT, 1/2 cad p/t lock type 5

4шт.

21

79399C1

ELBOW

1шт.

79400C1

PLUG, drain

1шт.

22

79401C1

BAR, throttle shut off

1шт.

86505867

BOLT,Hex, 1/4" - 20 x 1", Gr 5

1шт.

180044

SPRING

1/4 x 2 type 5

1шт.

120375

NUT,Hex, 1/4" - 20, Gr 5

4шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

23

79402C1

SUPPORT, front motor

1шт.

180175

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2 x 1-1/4 type 5

8шт.

120384

WASHER,1/2"

LOCK, 1/2"

8шт.

24

72266C1

END

rod

2шт.

25

79403C1

ROD, throttle

1шт.

26

79404C1

LINKAGE, throttle cross-over

1шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8 x 1 type 5

2шт.

27

79405C1

LEVER, throttle

1шт.

180181

BOLT,Hex, 1/2" - 13 x 2", Gr 5

1/2 x 2 type 5

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

2шт.

28

72125C1

GRIP, throttle

1шт.

29

79239C91

UNIT HEATER

HEATER, block

1шт.

30

73864C1

GASKET, air inlet

1шт.

31

79406C1

ADAPTER, air inlet

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

30167R1

NUT,M8, Cl 10

M8 phc class 10

2шт.

32

75037C1

HOSE

ELBOW, Air Inlet

1шт.

681209C1

HOSE CLAMP,#32, 1.56/2.50 Type F Worm, W/liner

CLAMP, no. 32 shoe type F hose

1шт.

33

79407C1

TUBE, air inlet 2" Diameter, 6, 6" Length

1шт.

34

73862C1

HOSE, adapter

1шт.

681209C1

HOSE CLAMP,#32, 1.56/2.50 Type F Worm, W/liner

CLAMP, no. 32 shoe type F hose

1шт.

995222R1

CLAMP

no. 36 type F hose

1шт.

35

72252C91

CLEANER ASSY, air

1шт.

72253C1

ELEMENT

air cleaner

1шт.

72254C1

WASHER, gasket

1шт.

72255C1

SCREW, thumb

1шт.

72256C1

CLAMP ASSY

1шт.

72257C1

BAFFLE ASSY

1шт.

72258C1

CUP ASSY

1шт.

72259C1

CAP, air stack

1шт.

72260C1

FILTER, precleaner, Optional

1шт.

36

79408C1

PIPE, exhaust

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

3шт.

30284R1

NUT,M10, Cl 10

M10 class 10

3шт.

37

73866C1

GASKET, exhaust

1шт.

38

74779C1

GASKET

thermostat

1шт.

39

79344C1

HOUSING, thermostat

1шт.

40

72221C1

ELBOW

2шт.

41

79410C1

PIPE, exhaust

1шт.

72249C1

CLAMP

muffler

1шт.

42

76476C1

BAFFLE, heat

1шт.

43

76478C1

BRACKET, muffler

2шт.

120377

NUT,3/8" - 16, Gr 5

8шт.

120394

WASHER,3/8", SAE

WASHER, .406 x .812 x .051

12шт.

44

76477C1

MUFFLER

1шт.

72249C1

CLAMP

muffler

2шт.

45

79411C1

HOSE, radiator

1шт.

27724R1

HOSE CLAMP,#24, 1.06/2.00 Type F Worm, W/liner

CLAMP, no. 24 shoe type F hose

2шт.

46

79412C1

TANK, water

1шт.

72265C1

CAP

radiator

1шт.

12696R1

BOLT, 3/8 x 1-1/4 phc crg type 1

4шт.

120394

WASHER,3/8", SAE

WASHER, .406 x .812 x .051

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

47

NSS

NOT SOLD SEPARAT

HOSE, vent, Use 40 in. from 50 ft. roll marked 417199C1

1шт.

279025R91

HOSE CLAMP,#06, .44/.78 Type F Worm

2шт.

48

79413C1

MANIFOLD, outlet

1шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

1шт.

120377

NUT,3/8" - 16, Gr 5

1шт.

50

NSS

NOT SOLD SEPARAT

HOSE, cooler to manifold, Use 18 in. from 50 ft. roll marked 73200C1

1шт.

51

NSS

NOT SOLD SEPARAT

HOSE, cooler to manifold, Use 22 in. from 50 ft. roll marked 73200C1

1шт.

52

NSS

NOT SOLD SEPARAT

HOSE, cooler to manifold, Use 28 in. from 50 ft. roll marked 73200C1

1шт.

53

79414C1

MANIFOLD, inlet

1шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

1шт.

120377

NUT,3/8" - 16, Gr 5

1шт.

54

NSS

NOT SOLD SEPARAT

HOSE, cooler to manifold, Use 24 in. from 50 ft. roll marked 73200C1

1шт.

27861R1

HOSE CLAMP,#10, .56/1.06 Type F Worm, W/liner

CLAMP, no. 10 shoe type F hose

36шт.

55

78158C1

COOLER

oil

9шт.

56

78164C1

STRIP, foam 18 in.

2шт.

56

78165C1

STRIP, foam 24 in.

2шт.

57

79415C1

SHROUD, fan

1шт.

18707R1

CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2

BOLT, 1/2 x 1 crg type 1

2шт.

120384

WASHER,1/2"

LOCK, 1/2"

2шт.

120387

WASHER,3/8" x 3/4" x .060"

.375 x .750 x .054

2шт.

58

73871C1

ADAPTER, hose

1шт.

59

78242C1

BELLEVILLE WASHER

spring

2шт.

60

72007C1

PAD, friction

1шт.

61

NSS

NOT SOLD SEPARAT

HOSE, breather, Use 6 in. from 50 ft. roll marked 526602R1

1шт.

27861R1

HOSE CLAMP,#10, .56/1.06 Type F Worm, W/liner

CLAMP, no. 10 shoe type F hose

2шт.

Выбрано товаров: 125
