Запчасти Case IH 4120 (04-1) - BRAKES, PARK BRAKE ATTACHMENT, CONSISTS OF THE FOLLOWING (5.1) - BRAKES

73775C1

BRAKE ASSY, park

1шт.

73776C1

SUPPORT, brake lever - extension

1шт.

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

2шт.

120375

NUT,Hex, 1/4" - 20, Gr 5

2шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

73777C1

DISC, brake

1шт.

73778C1

HOUSING, brake

1шт.

73779C1

SHAFT, brake

1шт.

73780C1

SEAL

1шт.

73781C1

BEARING

1шт.

72427C1

GEAR, pinion

1шт.

133213R1

SNAP RING,1.562", Int, #156

RING, retaining

1шт.

27997R1

RING, retaining

1шт.

73783C1

GASKET

2шт.

124549

WOODRUFF KEY,#9, 3/16" x 3/4", HT

1шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

6шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4 type 5

1шт.

20893R1

WASHER

.344 x 1.000 x .105

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

179849

BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5

2шт.

73784C1

ROD, control

1шт.

120368

NUT,5/16"-24, G5

1шт.

73785C1

CLEVIS, rod end

1шт.

180081

BOLT,Hex, 5/16"-18 x 1 1/4", G5

2шт.

120376

NUT,5/16"-18, G5

6шт.

73786C1

LEVER

1шт.

73787C1

CAM

1шт.

73788C1

BRACKET, lever mtg.

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

120388

.438 x 1.000 x 0.64

3шт.

73789C1

BAR, lever stop

1шт.
