Артикул
Название
Примечание
Количество
1
86977688
45 ELBOW,1-5/16" - 12 JIC x 1-5/16" - 12 ORB
Incl 2
1шт.
2
167268
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
1шт.
3
87301688
CLAMP,41.2mm, Coat, P Type
1шт.
5
43138
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
1шт.
6
87374752
GAUGE
Liquid Level Gauge
1шт.
7
87659238
HOSE
Hose, Oil Cooler Return, 825mm (32 1/2 in.)
1шт.
8
9790547
TEE,1 5/16"-12, 37 Degree x 1"-11 1/2, NPTF Br
1шт.
9
87029969
HYD CONNECTOR
1шт.
10
87035993
PLUG,Sq Soc, 2"-11 1/2 NPTF
1шт.
11
189310A1
STRAINER ASSY.
Suction Line Filter
1шт.
12
87039085
HOSE CLAMP,32mm - 54mm
2шт.
13
9615396
ELBOW,90 Degree, 1 5/16"-12, 37 Degree x 3/4"-14, NPTF
If Used
1шт.
13
87690479
TEE
Male 37Fl 1.0 x .75 x .75NPTF
1шт.
14
87547024
HOSE,25.4mm ID x 1553mm L, SAE 100R4
Hose, Charge Pump Supply, 1553mm (61 1/8 in.)
1шт.
15
87430661
FILTER
Hydraulic Filter; Incl 16 - 18
1шт.
16
N13268
PRESSURE SWITCH
1шт.
18
87439984
FILTER HEAD
Head Assembly
1шт.
19
87348364
HOSE ASSY.
Hose, Loader Pump Supply, 1380mm (54 5/16 in.)
1шт.
20
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP
3шт.
21
86637977
CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type
2шт.
22
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
4шт.
24
122158A1
NUT,M8, U
2шт.
25
268277
90 ELBOW,1-5/16" - 12 JIC x 1-5/16" - 12 ORB
Incl 26
1шт.
26
167268
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
1шт.
27
87349721
HYDRAULIC MOTOR,660CC
Drive Motor
2шт.
27
87349721R
REMAN-HYD MOTOR
450 - SKID STEER, TIER 3, P.I.N. N7M464019
2шт.
27
87349721C
CORE-MOTOR HYDRAULIC
Return Number
2шт.
28
87033824
FITTING,45 Degree, 1 1/4" Hose x 1 5/16"-12 ORB Beaded
Incl 29
1шт.
30
87547026
HOSE
Hose, EH Supply Or Brake, 465mm (18 5/16 in.)
2шт.
31
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
2шт.
32
86977790
BOLT,Hex, M6 x 45mm, Cl 8.8
2шт.
33
87404992
SQUARE NUT,M6 x 1.0, Cl 8
2шт.
34
87437351
MANIFOLD
Oil Return Manifold
1шт.
35
76349
PLUG,9/16" - 18 ORB
Incl. 36
1шт.
37
87554297
HYD TUBE,10.2 mm ID x 12.7 mm OD x 147, 99.2 mm L
Tube, Tandem Pump Supply
1шт.
38
87384126
HOSE ASSY.
Hose, Brake 250mm (9 27/32 in.)
1шт.
39
87547047
HOSE,12.7mm ID x 520mm L
Multi Valve Drain
1шт.
40
86508571
BOLT,Hex, M8 x 90mm, Cl 8.8
2шт.
41
84384
HYD CONNECTOR,9/16"-18, 37 Degree x 7/16"-20, O-Ring
Incl 42
3шт.
42
165202
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
43
87593247
ELBOW
Incl 44
1шт.
44
165202
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
45
87547043
HOSE,9.53mm ID x 773mm L
Dump Valve Supply
1шт.
46
87547033
HOSE,9.65 mm ID x 720.00 mm
Dump Valve Drain
1шт.
47
87547015
HOSE
Hose, Valve Supply, 412mm (16 7/32 in.)
1шт.
48
87546977
PUMP,46 CC
Rexroth Pump, A22 360 Bar, 5.7mm Orifice; See Fig 06-22
1шт.
48
87546977R
Remanufactured Hydraulic Pump; For N.A. only
REMAN-HYD PUMP
1шт.
48
87546977C
Return Number, for N.A. Only
CORE-HYDRAULIC PUMP
1шт.
49
378970
HYD CONNECTOR,1-5/16" - 12 ORB x 1-5/16" - 12 JIC
Incl 50
1шт.
50
167268
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
1шт.
51
87659239
HOSE
Hose, Filter To Cooler, 1140mm (44 7/8 in.)
1шт.
52
87707681
ANGLE
1шт.
53
87659241
Oil Cooler Bypass; See Fig 06-18A
1шт.
54
219603
90 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12, 37 Degree Fem Sw
1шт.
Выбрано товаров: 59
