Запчасти Case IH 450 (02-34) - WATER PUMP - CONTROL (02) - ENGINE

1

2852163

SUPPORT

1шт.

2

2852161

BELT TENSIONER

1шт.

3

2853006

PULLEY,65mm OD

1шт.

4

86982450

V-BELT

See Figure 02-02

1шт.

5

4899031

BOLT,Flng, M8 x 1.25 x 25mm

2шт.

6

4899109

SCREW,Hex, M10 x 1.5 x 80

1шт.

7

REF

INSTRUCTION

ALTERNATOR; See Figure 04-02

1шт.

8

REF

INSTRUCTION

WATER PUMP; See Figure 02-31

1шт.

9

REF

INSTRUCTION

FAN DRIVE; See Figure 02-35

1шт.

10

REF

INSTRUCTION

CRANKSHAFT PULLEY; See Figure 02-25

1шт.
