Артикул
Название
Примечание
Количество
1
87423833
PEDAL ASSY.
If Used
1шт.
1
87741562
PEDAL
1шт.
2
87033290
CARRIAGE BOLT,Sht Sq Nk, M12 x 55mm, Cl 8.8
1шт.
3
140018
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
1шт.
4
L14781
BUSHING,12.8mm ID x 15.94mm OD x 25.4mm L
1шт.
5
832-41412
NUT,M12 x 1.75, Cl 10
If Used
1шт.
5
412672
NUT,Hex, M12 x 1.75, Cl 10
1шт.
6
86977786
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8
Replaces 614-6025
1шт.
7
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
2шт.
8
86500688
NUT,Hex, M6 x 1.0, Cl 10.9
Replaces 829-1406
1шт.
87444161
LINKAGE
Incl 9-12
1шт.
9
L53928
BALL JOINT
1шт.
10
86976064
JAM NUT,Jam, 1/4"-28, G5
1шт.
11
87444164
ROD
1шт.
12
87444160
CLEVIS
1/4
1шт.
13
81827427
HYD CONNECTOR,3/4" - 16 JIC x 3/4" - 16 ORB
Incl 14
2шт.
15
87017348
VALVE
Secondary Auxiliary; See Figure 08-18
1шт.
16
16044321
BOLT,M8 x 1.25 x 55mm, Cl 8.8
1шт.
17
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
18
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
M8 x 1-1/4
2шт.
19
144124
HYD CONNECTOR,1-1/16" - 12 JIC x 7/8" - 14 ORB
Incl. 20
1шт.
21
87451963
HOSE ASSY.
Secondary Auxiliary Inlet; Used With Mech Control
1шт.
21
87603115
HOSE
Secondary Auxiliary Inlet; Used With Pilot Control
1шт.
22
D131983
COTTER PIN,1.04mm OD x 21.4mm L, Ring
1шт.
23
H32961
CLEVIS COUPLING,7.94mm OD x 29.34mm L
1шт.
25
129878A1
FITTING
Power Beyond; Incl. 26 - 28
1шт.
27
A52424
BACK-UP RING
1шт.
28
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
29
218-1703
REDUCER,37 Degree, 7/8"-14, Fem x 1 1/16"-12 Male
If Used
1шт.
29
87303664
HYD CONNECTOR
Adapter Tube 37Fl .625 x .75
1шт.
30
128819
HYD CONNECTOR,7/8" - 14 ORB x 3/4" - 16 JIC
If Used; Incl. 31; If Used
2шт.
31
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
32
139618A1
DECAL
Aux Hyd Control; See Fig 09-43
1шт.
Выбрано товаров: 40
