Артикул
Название
Примечание
Количество
1
378970
HYD CONNECTOR,1-5/16" - 12 ORB x 1-5/16" - 12 JIC
Incl 2
2-3шт.
2
167268
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
2-3шт.
3
87659201
HOSE
Hose, Upper Cooler, 885mm (34 13/16 in.)
1шт.
4
43138
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
1шт.
6
87648719
CLAMP,36.5mm, Coat, 10.3mm Bolt Hole, P Type
Clamp, Insulated 36.5mm X 3/8 Bolt
1шт.
7
87374752
GAUGE
Liquid Level Gauge
1шт.
8
189310A1
STRAINER ASSY.
Suction Line Filter
1шт.
9
87029969
HYD CONNECTOR
Stem, 90 Bead Hose 1.25 ID X 1.25 NPTF
1шт.
10
87039085
HOSE CLAMP,32mm - 54mm
2шт.
11
87437352
HYD TUBE,25.40 mm OD
Case Drain Tube
1шт.
12
9615396
ELBOW,90 Degree, 1 5/16"-12, 37 Degree x 3/4"-14, NPTF
If Used
1шт.
13
87659213
HOSE
Hose, Lower Cooler, 1010mm (39 3/4 in.)
1шт.
14
87707681
ANGLE
Filter Mounting Bracket
1шт.
16
86639325
WASHER,10.8mm ID x 24.5mm OD x 3mm Thk
2шт.
17
268277
90 ELBOW,1-5/16" - 12 JIC x 1-5/16" - 12 ORB
Incl 18
1шт.
18
167268
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
1шт.
19
86633356
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
2шт.
21
100016
NUT,M10 x 1.5, Cl 8
2шт.
22
87430661
FILTER
Incl 23 - 25
1шт.
23
N13268
PRESSURE SWITCH
1шт.
25
87439984
FILTER HEAD
Head Assembly
1шт.
26
87419597
HYD TUBE,25.40 mm OD x 658.9, 414.8 mm L
Valve Outlet
1шт.
27
87421217
ADAPTER,1-5/16" - 12 JIC x 1-1/16" - 12 JIC x 1-1/16" - 12 ORB
45 Deg With Side Outlet
1шт.
28
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
29
219606
CAP,1-1/16" - 12 JIC
1шт.
30
87396046
HOSE
Charge Suction, 1500mm (59 1/16 in.); If Used
1шт.
30
87719074
HOSE
Charge Suction, 1525mm (60.04 in.)
1шт.
31
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
If Used
1шт.
32
80681
LOCK WASHER,5/16"
If Used
1шт.
33
120103
BOLT,M8 x 1.25 x 16mm, Cl 8.8
If Used
1шт.
34
86637998
CLAMP,38.1mm, Coat, 10.3mm Bolt Hole, P Type
If Used
1шт.
35
9790547
TEE,1 5/16"-12, 37 Degree x 1"-11 1/2, NPTF Br
1шт.
36
86977790
BOLT,Hex, M6 x 45mm, Cl 8.8
2шт.
37
86517328
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk
2шт.
38
87404992
SQUARE NUT,M6 x 1.0, Cl 8
Square M6 1.0Cl 8 Znd
2шт.
39
86637977
CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
40
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
2шт.
41
140016
WASHER,M8 x 16mm OD x 1.6mm Thk
2шт.
42
122158A1
NUT,M8, U
2шт.
43
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP
3шт.
44
9827902
CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
45
87016615
WASHER,15.3mm ID x 28.5mm OD x 3mm Thk
2шт.
46
87637186
NUT
M14 Cl 10 Znd
2шт.
47
87564723
WASHER,15.3mm ID x 28.5mm OD x 6mm Thk
15.3 x 28.5 x 6mm
4шт.
48
87556906
BOLT,Hex, M14 x 70mm, Cl 10.9
2шт.
49
87033824
FITTING,45 Degree, 1 1/4" Hose x 1 5/16"-12 ORB Beaded
1шт.
50
87597549
HYDRAULIC HOSE,31.75 mm ID x 1320.00 mm, SAE 100R4
Gear Suction
1шт.
51
514920
HOSE CLAMP,20.6mm - 38.1mm, Worm Gear
If Used
1шт.
52
87393628
ADAPTER,1" Hose Barb x 1-5/16" - 12 ORB
90 Deg 1 Hose x 1 5/16 - 12; If Used
1шт.
52
87681206
Connector 45 Deg 1 Hose x 1 5/8 - 12; If Used
45 ELBOW
1шт.
52
87029968
HYD CONNECTOR
Stem 45 Bead Hose 1.0 ID X1-5-16-12 Thd
1шт.
53
87670
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
2шт.
54
86625255
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
2шт.
55
87597562
HOSE,15.88mm ID x 500mm L
Valve Supply; If Used
1шт.
56
84570
90 ELBOW,7/8" - 14 JIC x 1-1/16" - 12 ORB
If Used
1шт.
57
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
If Used
1шт.
Выбрано товаров: 60
