87617100
SERVICE KIT
Kit, High Flow Bi-Directional Gear; Incl 1- 22 And 08-17, 08-18
1шт.
87719310
SERVICE KIT
Europe, High Flow Bi-Directional Gear; Incl 1-22 And Fig 08-17, 08-18, 06-30A
1шт.
1
REF
INSTRUCTION
Accumulator, See Fig 08-07
1шт.
2
87546975
HYDRAULIC VALVE
Control Valve, See Fig 08-23
1шт.
3
87012669
VALVE
See Fig 08-19
1шт.
4
87020733
PUMP
See Fig 06-55
1шт.
5
272310
O-RING,0.07" Thk x 3.239" ID, -42, Cl 5, 75 Duro
1шт.
6
120061
BOLT,Hex, M8 x 60mm L, Cl 8.8
1шт.
7
80681
LOCK WASHER,5/16"
2шт.
8
257859A1
PLATE, SPACER,31.8mm W x 68mm L x 4.76mm Thk
PLATE,SPACER
3шт.
9
1546028C1
CLAMP,25.4mm ID x 82mm L
25.4 x 25.4
2шт.
10
9628098
NUT,M8 x 1.25, Cl 10
2шт.
11
87454000
HOSE ASSY.
860 mm (38.85 in) High Flow
1шт.
12
87453999
HOSE ASSY.
1020 mm (40.15 in) High Flow
1шт.
13
87602204
HOSE
1200 mm (47.24 in) High Flow Suction
1шт.
14
86639006
CLAMP,38.1mm, Coat, 13.5mm Bolt Hole, P Type
1шт.
15
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
1шт.
16
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
1шт.
17
9618946
TEE,37 Degree, 1 5/16"-12 x 1 5/16"-12, Fem Sw Run
1шт.
18
REF
INSTRUCTION
Auxiliary Hydraulics, See Fig 08-17
1шт.
19
87414769
SWITCH
Rocker, High Flow
1шт.
20
87447970
HARNESS
Electro-Hydraulic Auxiliary
1шт.
21
128818
UNION,3/4" - 16 ORB x 3/4" - 16 JIC
Incl 22
1шт.
22
128825
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
