Запчасти Case IH 435 (02-36) - POWER TAKE OFF (02) - ENGINE

1

2853044

DRIVE ASSY.

Drive Assy, Hydraulic Pump

1шт.

2

2853495

SNAP RING,2.5mm Thk

Ring, Locking

1шт.

3

4897110

O-RING,0.139" Thk x 3.859" ID, -241

1шт.

4

4895875

SPACER,103mm ID x 107.8mm OD x 30mm L

1шт.

5

REF

INSTRUCTION

See Figure 02-09, 02-10, Cylinder Block

1шт.

6

2830506

ADAPTER

Incl. 7 - 10

1шт.

7

2831290

O-RING

1шт.

8

4895143

O-RING

1шт.

9

4895875

SPACER,103mm ID x 107.8mm OD x 30mm L

1шт.

10

2831392

SNAP RING,M97

1шт.
