Артикул
Название
Примечание
Количество
1
87450536
A/C HOSE,990.6/39 mm L
AC Drain
1шт.
2
87436121
HOSE,10.31mm ID x 1701.8mm L
Incl. O-ring 128484A1
1шт.
128484A1
O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro
10.82 ID
1шт.
3
87436118
A/C HOSE
Incl. O-ring 128485A1
1шт.
128485A1
O-RING,1.78mm Thk x 14mm ID, 70 Duro
14.00 ID
1шт.
4
87000312
CABLE TIE,4.8mm W x 203.2mm OAL, Nylon
CABLE STRAP
10шт.
5
9706732
CLAMP,19mm ID, 8.7mm Bolt Hole, P Type
25.4mm 3/8 in Bolt
1шт.
6
H434289
MOUNTING CLIP,7/8”, Insulated, 1/2” Bolt
22.2 dia, Double
2шт.
7
308651A1
COVER
1-3/16 in; If Used
1шт.
7
87462219
PROTECTION STRIP
1.0 in; If Used
1шт.
7a
87360940
TUBE,15.88 mm OD
Heater Tube; Formed Length 300 mm (11.8 in); Used With 9A
1шт.
7a
87531822
HEATER TUBE,.625" OD
Heater Tube; Formed Length 135 mm (5.3 in); Used With 9A; Replaces 87360940
1шт.
7a
87612366
HEATER TUBE
"L" Formed Tube, 135mm (5.3 in); If Used
1шт.
8
87439845
GUARD
ROPS Rear Bottom
2шт.
9
87438210
HEATER HOSE,15.88 mm ID x 1830.00 mm, SAE 20R3
Supply
1шт.
9a
87383270
HEATER HOSE,15.88 mm ID x 1460.00 mm, SAE 20R3, SAE J20
1шт.
9a
87438212
HEATER HOSE,15.88 mm ID x 1900.00 mm, SAE 20R3
Supply, Used with 7A; Replaces 87383270
1шт.
10
412250
NUT,M8 x 1.25, Cl 8
6шт.
11
86512420
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8
If Used
6шт.
12
86624185
WASHER,8.8mm ID x 17.5mm OD x 2mm Thk
6шт.
13
87439844
GUARD
ROPS Front
2шт.
14
87436383
HOSE ASSY.
2806 mm (110 1/2 in.) Length; If Used
1шт.
14
87574330
HOSE
2705 mm (106 1/2 in.) Length; If Used
1шт.
15
87436117
A/C HOSE,12.7mm ID x 3657.6mm L
Incl. O-ring 128485A1
1шт.
128485A1
O-RING,1.78mm Thk x 14mm ID, 70 Duro
14.00 ID
1шт.
16
87439990
GUARD,46mm ID x 900mm L, Nylon Woven
Heater Hose
1шт.
17
87438213
HEATER HOSE,15.88mm ID x 3215mm L, SAE 20R3
Return
1шт.
18
295076A1
SEAL
ROPS Pivot Pin
2шт.
19
87036372
SEALING STRIP
Lower Front ROPS
1шт.
20
87441006
TUBE,4.6mm ID x 1350mm L
AC Hoses
1шт.
21
642560
FITTING,5/8" Hose x 3/8" NPTF Beaded
1шт.
21a
87302136
FITTING,5/8" Hose x 1/2" NPTF, Barbed
If Used
1шт.
22
87000223
HOSE CLAMP,22mm ID Static x 15mm W, Spring Type
No Longer Used, Order 87443511
8шт.
22
87443511
CLAMP,22mm - 26mm, CTB-24, Style C
8шт.
22a
242680
HYD CONNECTOR,7/8" - 14 JIC x 1/2" - 14 NPT
Used With 7A, 9A
1шт.
23
87036371
SEAL
Lower Side ROPS
2шт.
24
87033596
COVER
106 mm (4.17 in) Width Of Flat To First Bend; If Used
2шт.
24
87460906
COVER
118.8 mm (4.68 in) Width Of Flat To First Bend; Used With ROPS 87461181, See Figure 09-23
2шт.
25
87443444
SLEEVE
Heat Protective
2шт.
26
87438211
HEATER HOSE,15.88 mm ID x 2985.00 mm, SAE 20R3
Supply
1шт.
27
87436120
HOSE,7.92mm ID x 3657.6mm L
Incl. O-Ring 128483A1
1шт.
28
87438212
HEATER HOSE,15.88 mm ID x 1900.00 mm, SAE 20R3
Return
1шт.
30
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
If Used
6шт.
30
87574372
SPACER,6.8mm ID x 10.3mm OD x 19mm L
If Used
4шт.
31
86979986
WASHER,0.34" ID x 1.25" OD x 0.06" Thk
If Used
2шт.
31
86592710
WASHER,6.4mm ID x 17mm OD x 3mm Thk
If Used
4шт.
32
87301324
NUT,Spring, M5 x 0.8
If Used
4шт.
Выбрано товаров: 51
