Артикул
Название
Примечание
Количество
1
87367444
HOSE,9.53mm ID x 3305mm L
Hose, Hydraulic Coupler, 3305mm (130 1/8 in.)
1шт.
2
86624005
CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type
4шт.
3
87642911
SWITCH
Rocker Switch, Hydraulic Coupler
1шт.
4
87440565
HOSE ASSY.,6.35mm ID x 720mm L
Hose, Step To Coupler, 720mm (28 11/32 in.)
1шт.
5
REF
INSTRUCTION
Coupler; See Fig 08-13
1шт.
7
87440564
HOSE ASSY.,6.35mm ID x 690mm L
Hose, Step To Coupler, 690mm (27 3/16 in.)
1шт.
8
87423807
PLATE
1шт.
9
87446825
TEE
1шт.
10
87367445
HOSE,9.53mm ID x 2482mm L
Hose, Hydraulic Coupler, 2482mm (97 11/16 in.)
1шт.
11
87413436
HOSE ASSY.
Hose, Case Drain, 655mm (25 13/16 in.)
1шт.
12
87421480
HYDRAULIC VALVE
1шт.
17
338413
BOLT,Hex, M6 x 60mm, Cl 8.8
2шт.
18
86512440
NUT,M6, Cl 10
4шт.
19
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
8шт.
Выбрано товаров: 22
