Запчасти Case IH 75 (A-05[B]) - REAR APRON SHAFT

1

613022R1

BEARING, apron shaft

2шт.

219-31

LUBE NIPPLE,30 Degree Elbow, 1/8" - 27 NPTF

LUB-FTG, 1/8" - 30 degree elbow (LH)

1шт.

2

613026R1

SUPPORT, shaft brg

2шт.

14994R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, , w/Nut Short NK, 5/16"-18 x 3/4", G2

6шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

6шт.

3

613068R2

SPROCKET, 6T apron shaft

2шт.

19479R1

PIN,1/4" x 2", Coiled

2шт.

457400R1

KEY,5/16" Sq x 1 3/4", Par

5/16 x 5/16 x 1-3/4" straight

2шт.

4

613075R1

SHAFT, rear apron

1шт.

432-1628

COTTER PIN,1/4" x 1 3/4"

Pin, Split (Cotter), 1/4" x 1 3/4"

2шт.

68049H

WASHER

WASH, 1-5/32 x 1-1/2 x 16 ga

1шт.

5

613159R1

BRACKET, housing lubricator RH

1шт.

15016R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1 1/8" , Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1 1/8", G2

1шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

1шт.

6

144621

NIPPLE, LUBE,Nipple, 1/8" NPT x 5"

NIPPLE, 1/8 x 5" lube fitting

1шт.

7

105412

ELBOW,90 Degree, 1/8" NPT

1/8" - 90 degree brg nipple RH

1шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.
