Запчасти Case IH 570 (B-52) - UPPER BEATER AND SUPPORTS (00) - COMPLETE MACHINE

1

593062R1

VALVE BLOCK

SECTION, upper beater mounting

2шт.

180121

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5

3/8-16 x 7/8 hex hd

8шт.

120377

NUT,3/8" - 16, Gr 5

8шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

2

593063R11

SHAFT

ASSY, upper beater, for service on machines built prior to the 1977 season

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

1шт.

22481R1

WASHER

1.406 x 2.250 x .054

2шт.

3

593065R91

BEATER ASSY, no. 1 upper, includes 1-593074R1, tooth, 8-593073R1, tooth and 18-106916 rivet, for service on machines built prior to the 1977 season

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8-16 x 1 hex hd

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

3

593066R91

BEATER ASSY, no 2 upper, includes 1-593074R1, tooth, 8-593073R1, tooth and 18-106916, rivet, for service on machines built prior to the 1977 season

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8-16 x 1 hex hd

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

3

593067R91

BEATER ASSY, no 3 upper, includes 1-593075R1, tooth 8-593073R1, tooth and 18-106916, rivet, for sevice on machines built prior to the 1977 season

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8-16 x 1 hex hd

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

3

593068R91

BEATER ASSY, no 4 upper, includes 1-593075R1, tooth 8-593073R1, tooth and 18-106916, rivet, for service on machines built prior to the 1977 season

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8-16 x 1 hex hd

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

4

593074R1

TOOTH

beater LH single, for service on machines built prior to the 1977 season

2шт.

106916

RIVET,Tr Hd, 5/16" x 1"

5/16 x 1 truss-hd

4шт.

4

593075R1

TOOTH

beater RH single, for service on machines built prior to the 1977 season

2шт.

106916

RIVET,Tr Hd, 5/16" x 1"

5/16 x 1 truss-hd

4шт.

5

593073R1

TOOTH

beater double, for service on machines built prior to the 1977 season

32шт.

106916

RIVET,Tr Hd, 5/16" x 1"

5/16 x 1 truss hd

64шт.

6

593076R1

STRIP

beater bearing bracket

2шт.

550796R1

CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5

BOLT, 3/8-16 x 1-1/4 crg

8шт.

120377

NUT,3/8" - 16, Gr 5

8шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

7

593077R1

BAR

bearing bracket filler

4шт.

8

617863R1

FLANGED BEARING

RETAINER, beater shaft bearing

4шт.

495967R1

CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd

BOLT, 3/8-16 x 1 crg

6шт.

120377

NUT,3/8" - 16, Gr 5

6шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

6шт.

9

571588R92

BALL BEARING,1.3755" ID x 72 mm OD x 1"

upper beater shaft

2шт.

10

517645R11

COLLAR

ASSY, bearing locking, includes 1-102592, screw

2шт.

102592

SET SCREW,Hex Skt, 3/8" - 16 x 3/8"

SCREW, 3/8-16 x 3/8 cup pt set

2шт.

11

821189C1

BEATER ASSY, upper, for service on machines built 1977 season and since

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

1шт.

22481R1

WASHER

1.406 x 2.250 x .054

2шт.

12

821081C1

PLATE

upper beater, for service on machines built 1977 season and since

18шт.

24840R1

BOLT,Hex, 3/8" - 16 x 1", Gr 8

36шт.

25522R1

NUT,3/8"-16, G8

3/8-16 hex type 8

36шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

36шт.
