Запчасти Case IH 155 (J-19[A]) - RATCHET WHEEL SHIELD

1

609320R1

SUPPORT, shield upper hinge

1шт.

598803R1

CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5, Full Thd

BOLT, 5/16 x 1" crg

3шт.

120376

NUT,5/16"-18, G5

3шт.

22264R1

WASHER

13/32 x 1 x 7 ga

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

3шт.

2

609322R91

SHIELD, main drive & ratchet

1шт.

619856R1

WASHER

13/32 x 1 x 16 ga

2шт.

126032

WING NUT,3/8"-16

NUT, 3/8" wing

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

3

609321R11

SUPPORT, shield lower

1шт.

180121

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5

3/8 x 7/8"

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.
