Запчасти Case IH 103 (F-09[B]) - WIDESPREAD

Схема запчастей Case IH 103 - (F-09[B]) - WIDESPREAD

Артикул

Название

Примечание

Количество

1

615274R1

WASHER,32.54mm ID x 63.5mm OD x 3.4mm Thk

1-9/32 x 2-1/2 x 11 ga

2шт.

2

619671R91

ROLLER BEARING,31.75mm ID x 47.63mm OD x 50.8mm W

shaft (opt w/609048R91)

2шт.

2

609048R91

BEARING

shaft (opt w/619671R91)

2шт.

3

614554R2

HOUSING

brg

2шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, (LH) 1/8"-27 x .66 lg

1шт.

219-31

LUBE NIPPLE,30 Degree Elbow, 1/8" - 27 NPTF

LUB-FTG, 1/8" - 30 degree elbow (RH)

1шт.

4

614553R1

HOUSING

PLATE, brg housing stop

2шт.

18684R1

BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2

W/NUT, 3/8 x 1-1/4" cd-pltd crg

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

5

614552R1

PLATE, brg housing, Serial Range: (prior-1964)

2шт.

19019R1

CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2

BOLT W/NUT, 3/8 x 1" cd-pltd no. 3 plow

8шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

5

609116R11

SUPPORT

brg housing (1964 & since)

2шт.

19417R1

BOLT

W/NUT, 3/8 x 1" cd-pltd crg

4шт.

18684R1

BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2

W/NUT, 3/8 x 1-1/4" cd-pltd crg

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

6

Q121

WASHER

1-9/32 x 2 x 16 ga

2шт.

7

BEATER, widespread (prior to 1964 order 1-609054R91, widespread; 1-608053R1, ring; 2-614554R2, housing & 2-615274R1, wash

1шт.

119181

C-PIN, 1/4 x 1-7/8"

1шт.

7

609054R91

BEATER, widespread (1964 & since)

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

1шт.

Выбрано товаров: 21
