Запчасти Case IH 103 (F-08[A]) - REAR SIDE SHIELD

1

614543R1

COVER, rear shield

1шт.

19282R1

BOLT

W/NUT, 1/4 x 1/2" cd-pltd crg

5шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

5шт.

2

614540R11

SHIELD, rear drive

1шт.

3

614530R1

ROD, hinge coupling

1шт.

4

614529R1

HINGE, side shield

1шт.

18404R1

CARRIAGE BOLT,Short Sq Nk, 1/4" - 20 x 5/8", Gr 2

BOLT W/NUT, 1/4 x 5/8" cd-pltd crg

2шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

5

454502R1

LATCH

rear shield

2шт.

Q1505

WASHER

WASH, 13/32 x 1 x 16 ga

2шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

2шт.

6

M296

SPRING

shield latch

2шт.

7

614544R1

BRACKET, rear shield support

2шт.

14990R1

BOLT

W/NUT, 5/16 x 5/8" crg

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.
