Запчасти Case IH 103 (F-06) - FRONT DRIVESHAFT

Схема запчастей Case IH 103 - (F-06) - FRONT DRIVESHAFT

Артикул

Название

Примечание

Количество

1

B12219

WASHER

knuckle

1шт.

2

619669R91

BEARING ASSY,1.125" ID x 1.503" OD x 2"

shaft front (opt w/609046R91)

1шт.

2

609046R91

BEARING

shaft front (opt w/619669R91)

1шт.

3

619541R1

CASE

HOUSING, front brg

1шт.

332040

LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg

LUB-FTG, 1/8" - 90 degree elbow

1шт.

4

612801R1

PLATE, brg housing support

1шт.

17420R1

BOLT,Hex, 3/8"-16 x 7/8", G2

W/NUT, 3/8 x 7/8" mach

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT W/NUT, 3/8 x 1" crg

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

5

613259R91

SUPPORT, driveshaft front

1шт.

17420R1

BOLT,Hex, 3/8"-16 x 7/8", G2

W/NUT, 3/8 x 7/8" mach

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

6

607993R1

SHIELD

COVER, PTO shield

1шт.

17426R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

W/NUT, 3/8 x 1" mach

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

7

612789R1

BRACE, driveshaft support LH

1шт.

7

612790R1

BRACE, driveshaft support RH

1шт.

17426R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

W/NUT, 3/8 x 1" mach

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

8

619603R1

PLATE

STRAP, brg housing stop

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT W/NUT, 3/8 x 1" crg

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

9

614512R1

SHAFT, front drive

1шт.

Q162

WASHER

WASH, 1-5/32 x 1-3/4 x 16 ga

1шт.

10

619664R1

SHIELD, drive shaft

1шт.

11

614521R91

SHIELD, drive belt front

1шт.

19419R1

BOLT, 5/16 x 1/2" cd-pltd mach

2шт.

18473R1

SCREW,Hex, 5/16"-18 X 5/8", G2

BOLT W/NUT, 5/16 x 5/8" cd-pltd mach

1шт.

19416R1

BOLT

W/NUT, 5/16 x 3/4" cd-pltd crg

1шт.

134238R1

WASHER

WASH, 11/32 x 1 x 16 ga cd-pltd

3шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

4шт.

12

614524R1

BRACKET, shield upper

1шт.

86508749

CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5

BOLT W/NUT, 3/8 x 1-1/4" crg

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

13

565631R1

BEARING CAP,2.441" ID x 4.4375" OD x 0.34375"

TTE, rear brg

2шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT W/NUT, 3/8 x 1" crg

2шт.

86508749

CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5

BOLT W/NUT, 3/8 x 1-1/4" crg

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

14

455960R91

BALL BEARING

BEARING, shaft rear (Fafnir or New Departure, w/557115R11, collar)

1шт.

14

610536R91

BEARING

shaft rear (SKF w/610537R11, collar)

1шт.

15

557115R11

COLLAR

COLLAR, brg locking (includes screw, 115321) Fafnir or New Departure, use w/455960R91, brg)

1шт.

115321

SET SCREW,Hex Skt, 5/16"-18 x 5/16"

SCREW, 5/16 x 5/16" hdls cup-pt set

1шт.

15

610537R11

COLLAR

brg locking (includes screw, 115321) (SKF use w/610536R91, brg)

1шт.

115321

SET SCREW,Hex Skt, 5/16"-18 x 5/16"

SCREW, 5/16 x 5/16" hdls cup-pt set

1шт.

16

614513R1

PULLEY, front drive main (540 RPM)

1шт.

608597R1

PULLEY, front drive main (1000 RPM)

1шт.

Y24430

KEY,1/4" Sq x 1 1/2", Par

1/4 x 1/4 x 1-1/2" straight

1шт.

576482R1

LOCK PIN,5/16" x 2", Slotted

1шт.

17

614525R1

BRACKET, belt shield lower

1шт.

17411R1

BOLT,Hex, 5/16"-18 X 3/4", G2

W/NUT, 5/16 x 3/4" mach

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

Выбрано товаров: 51
