Запчасти Case IH 125 (D-18[A]) - GEAR CASE SHIELD, 1963 SEASON AND SINCE

1

613562R21

SHIELD, gear case

1шт.

613127R1

NUT, 5/16" - NF speed

2шт.

113859

BOLT (SPREADER),Rd Hd, 5/16" - 18 x 1/2"

SCREW, 5/16 x 1/2" slt-rd-hd

2шт.

19428R1

BOLT W/NUT, 5/16 x 5/8" cd-pltd crg

2шт.

Q398

WASHER

WASH, 11/32 x 7/8 x 16 ga

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

2

613561R1

BRACKET, shield

1шт.

15001R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 7/8", Gr 2

BOLT, CARRIAGE, , w/Nut Short NK, 5/16"-18 x 7/8", G2, Full Thd

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

3

617412R1

SPROCKET, 6T chain tightener

2шт.

4

617502R11

TIGHTENER, chain inner

1шт.

5

619648R1

SUPPORT, inner chain tightener

1шт.

17437R1

BOLT W/NUT, 3/8 x 1-1/8" mach

1шт.

17448R1

BOLT (SPREADER)

BOLT W/NUT, 1/2 x 1-1/4" mach

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

6

618439R1

SPACER, tightener sprocket

2шт.

7

617503R11

TIGHTENER, chain outer

1шт.

8

620485R1

BOLT, tightener sprocket oil

2шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.

102637

NUT,1/2"-13, G5

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

9

617501R1

SUPPORT, outer chain tightener

1шт.

17420R1

BOLT,Hex, 3/8"-16 x 7/8", G2

W/NUT, 3/8 x 7/8" mach

1шт.

17437R1

BOLT W/NUT, 3/8 x 1-1/8" mach

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

10

617434R1

BOLT, chain tightener

1шт.

12026R1

WASHER

WASH, 17/32 x 1-1/4 x 16 ga

1шт.

102637

NUT,1/2"-13, G5

2шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

1шт.
