Запчасти Case IH 125 (D-16[A]) - UPPER BEATER

Схема запчастей Case IH 125 - (D-16[A]) - UPPER BEATER

Артикул

Название

Примечание

Количество

1

565631R1

BEARING CAP,2.441" ID x 4.4375" OD x 0.34375"

TTE, beater brg

4шт.

15015R1

SCREW,Sq Nk, 3/8" - 16 x 1 1/8"

BOLT W/NUT, 3/8 x 1-1/8" crg

6шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

6шт.

2

557995R11

COLLAR

brg locking (includes screw, 115321)

2шт.

115321

SET SCREW,Hex Skt, 5/16"-18 x 5/16"

SCREW, 5/16 x 5/16" hdls cup-pt set

2шт.

3

617668R91

BALL BEARING

beater shaft

2шт.

4

619596R1

SUPPORT, shaft brg

2шт.

19417R1

BOLT

W/NUT, 3/8 x 1" cd-pltd crg (4 - LH; 3 - RH)

1шт.

19480R1

BOLT W/NUT, 3/8 x 1-1/4" cd-pltd (RH)

1шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

5

617506R1

TOOTH

double

28шт.

106915

RIVET,Tr Hd, 5/16" x 7/8"

5/16 x 7/8" truss-hd

56шт.

6

619692R91

ANGLE, no. 1 (includes rivets, 106915 & teeth 617506R1)

6шт.

6

619693R91

ANGLE, no. 2 (includes rivets, 106915 & teeth 617506R1)

1шт.

6

619694R91

ANGLE, no. 3 (includes rivets, 106915 & teeth 617506R1)

1шт.

6

619695R91

ANGLE, no 4 (includes rivets, 106915 & teeth 617506R1)

1шт.

180121

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5

W/NUT, 3/8 x 7/8" cd-pltd type 2

12шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

12шт.

7

619548R11

SHAFT, upper beater

1шт.

8

619536R1

SPROCKET, 11T beater driven

1шт.

113879

KEY

5/16 x 1-1/4" Woodruff

1шт.

19479R1

PIN,1/4" x 2", Coiled

1шт.

Выбрано товаров: 22
