Запчасти Case IH 74L (50) - LIFT BOOM (82) - FRONT LOADER & BUCKET

Схема запчастей Case IH 74L - (50) - LIFT BOOM (82) - FRONT LOADER & BUCKET

Артикул

Название

Примечание

Количество

1

T94861

BOOM - lift (Machinery Item)

1шт.

4

T54639

FRAME

- main, fork lift attachment

1шт.

5

138-325

ROLL PIN - 7/16 x 2-1/4", fork lift attachment

2шт.

6

T54641

PIN

- fork lift attachment

2шт.

7

T54642

BUSHING

fork lift attachment

2шт.

8

181-805

SET SCREW,Sq Hd, 3/8"-16 x 1/2"

- 3/8 x 1/2" NC cup point, fork lift attachment

2шт.

9

T54640

TOOTH

fork lift attachment

2шт.

10

219-15

LUBE NIPPLE,5/16" NPTF

FITTING - grease 5/16" straight drive, fork lift attachment

4шт.

11

321-4735

DECAL

PLATE - decal limit 3870 pounds, fork lift attachment

1шт.

Выбрано товаров: 9
