(65) - CASE FRONT END LOADER (1/75-12/81)
/
(82) - FRONT LOADER & BUCKET
/

(58) - MATERIAL BUCKETS, MATERIAL BUCKETS WITH TINES

Запчасти Case IH 65 (58) - MATERIAL BUCKETS, MATERIAL BUCKETS WITH TINES (82) - FRONT LOADER & BUCKET

Схема запчастей Case IH 65 - (58) - MATERIAL BUCKETS, MATERIAL BUCKETS WITH TINES (82) - FRONT LOADER & BUCKET

№

Артикул

Название

Примечание

Количество

1

T92141

BUCKET - 60" with replaceable edge (Machinery Item), Includes: Ref. 2

1шт.

2

T50013

EDGE

- replaceable 68" for 60" bucket

1шт.

3

T92143

BUCKET - 66" with replaceable edge (Machinery Item), Includes: Ref. 4

1шт.

4

T52179

EDGE

- replaceable 74" for 66" bucket

1шт.

5

T92145

BUCKET - 72" with replaceable edge (Machinery Item), Includes: Ref. 6

1шт.

6

T50014

EDGE

- replaceable 80" for 72" bucket

1шт.

7

T92147

BUCKET - 83" with replaceable edge (Machinery Item), Includes: Ref. 8

1шт.

8

T50015

EDGE

- replaceabale 91" for 83" bucket

1шт.

15

T92142

BUCKET - 60" drilled for tines with replaceable edge (Machinery Item), Includes: Ref. 16, material buckets with tines

1шт.

16

T50013

EDGE

- replaceabale 68" for 60", material buckets with tines

1шт.

23

T89091

TINES - 24" long (60" bucket) (Machinery Item), Includes: Ref. 24 - 26, material buckets with tines

7шт.

24

13-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

- 3/8 x 2-1/2" NC hex (Grade 5), material buckets with tines

2шт.

25

92-6

LOCK WASHER,3/8"

material buckets with tines 3/8"

2шт.

26

25-106

NUT,3/8"-16, G5

- 3/8" NC hex, material buckets with tines

2шт.

17

T92144

BUCKET - 66" drilled for tines with replaceable edge (Machinery Item), Includes: Ref. 18, material buckets with tines

1шт.

18

T52179

EDGE

- replaceable 74" for 66", material buckets with tines

1шт.

23

T89091

TINES - 24" long (66" bucket) (Machinery Item), Includes: Ref. 24 - 26, material buckets with tines

8шт.

24

13-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

- 3/8 x 2-1/2" NC hex (Grade 5), material buckets with tines

2шт.

25

92-6

LOCK WASHER,3/8"

material buckets with tines 3/8"

2шт.

26

25-106

NUT,3/8"-16, G5

- 3/8" NC hex, material buckets with tines

2шт.

19

T92146

BUCKET - 72" drilled for tines with replaceable edge (Machinery Item), Includes: Ref. 20, material buckets with tines

1шт.

20

T50014

EDGE

- replaceable 80" for 72" bucket, material buckets with tines

1шт.

23

T89091

TINES - 24" long (72" bucket) (Machinery Item), Includes: Ref. 24 - 26, material buckets with tines

8шт.

24

13-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

- 3/8 x 2-1/2" NC hex (Grade 5), material buckets with tines

2шт.

25

92-6

LOCK WASHER,3/8"

material buckets with tines 3/8"

2шт.

26

25-106

NUT,3/8"-16, G5

- 3/8" NC hex, material buckets with tines

2шт.

21

T92148

BUCKET - 83" drilled for tines with replaceaable edge (Machinery Item), Includes: Ref. 22, material buckets with tines

1шт.

22

T50015

EDGE

- replaceable 91" for 83", material buckets with tines

1шт.

23

T89091

TINES - 24" long (83" bucket) (Machinery Item), Includes: Ref. 24 - 26, material buckets with tines

10шт.

24

13-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

- 3/8 x 2-1/2" NC hex (Grade 5), material buckets with tines

2шт.

25

92-6

LOCK WASHER,3/8"

material buckets with tines 3/8"

2шт.

26

25-106

NUT,3/8"-16, G5

- 3/8" NC hex, material buckets with tines

2шт.

Выбрано товаров: 32
