Запчасти Case IH 2455 (8-50) - DECALS

Схема запчастей Case IH 2455 - (8-50) - DECALS
8
7
9
10
4
1
2
6
5
3
11

Артикул

Название

Примечание

Количество

95995C91

PACKAGE

KIT - decal, CaseIH trademark and model designation, no longer available, order as needed the following below

1шт.

4

95730C1

DECAL

- CaseIH trademark, 1-5/8 x 4-1/16 inch

2шт.

4

95731C1

DECAL

- CaseIH trademark, 2-1/2 x 6-1/8 inch

2шт.

4

91401C1

DECAL

- CaseIH trademark, 3-5/16 x 8-3/16 inch

2шт.

4

95732C1

DECAL,Case IH Logo

- CaseIH trademark, 4-3/16 x 10-1/4 inch

2шт.

95993C91

DECAL

KIT - decal, Case International, no longer available, order as needed the following below

1шт.

5

1973420C1

DECAL

- Case International, 1 x 8-3/4 inch

2шт.

5

1973422C1

DECAL

- Case International, 1-9/16 x 14-1/32 inch

2шт.

5

192847A2

DECAL

- Case International, 2-1/8 x 19-5/16 inch

2шт.

5

1973425C1

DECAL

- Case International, 2-3/4 x 24-9/16 inch

2шт.

95994C91

DECAL

KIT - decal, Case International, for red background, no longer available, order as needed the following below

1шт.

6

1973427C1

DECAL

- Case International, 3-11/32 x 29-7/8 inch

2шт.

6

1973428C1

DECAL

- Case International, 2-3/8 x 39-11/32 inch

2шт.

96168C91

DECAL

KIT - decal, Case International, for black background, no longer available, order as needed the following below

1шт.

6

1978600C1

DECAL

- Case International, 1 x 1-13/32 inch

2шт.

6

1978601C1

DECAL

- Case International, 1-3/8 x 23-11/16 inch

2шт.

95996C91

DECAL

KIT - decal, model designation, no longer available, order as needed the following below

1шт.

7

96009C1

DECAL

- model designation, 1 inch

2шт.

7

96010C1

DECAL

- model designation, 1-9/16 inch

2шт.

7

96011C1

DECAL

- model designation, 2-5/32 inch

2шт.

7

96012C1

DECAL

- model designation, 2-3/4 inch

2шт.

95997C91

KIT

- decal, model number, no longer available, order as needed the following below

1шт.

7

96013C1

DECAL

- model designation, 3-5/16 inch

2шт.

7

96014C1

DECAL

- model designation, 3-3/8 inch

2шт.

7

96015C1

DECAL

- model designation, 4-1/2 inch

2шт.

8

70373C1

PRODUCT GRAPHIC

DECAL - caution

1шт.

9

220321A1

WARNING DECAL

DECAL - warning, read the operator's manual (replaces 1254170C1)

1шт.

10

1334171C1

DECAL

- warning, rollback prevention (replaces 852125C2)

1шт.

11

851836C1

PRODUCT GRAPHIC

DECAL - important, 2455 loader only

1шт.

Выбрано товаров: 29
